DIN terminal: AV□00-□-□D/Y□-□-A
Dimensions
Model
AV2000-□02-1 to 6D/Y(Z)□-A
AV3000-□03-1 to 6D/Y(Z)□-A
AV4000-□04-1 to 6D/Y(Z)□-A
AV5000-□06,10-1 to 6D/Y(Z)□-A
Model
AV2000-□02-1 to 6D/Y(Z)□-A
AV3000-□03-1 to 6D/Y(Z)□-A
AV4000-□04-1 to 6D/Y(Z)□-A
AV5000-□06,10-1 to 6D/Y(Z)□-A
Port size A
1(P) 2(A) 3(R)
1/4 1/4 1/4 66
3/8 3/8 3/8 76
1/2 1/2 1/2 98
3/4,1 3/4,1 3/4 128
With bracket
K L M N P
30 50 51.5 44 5.5
41 50 53.5 46 5.5
50 60 64 54 8.5
70 75 70 60 11
-29-
Standard specifications
B C D E1
97 47 24.5 20
97 50 29.5 20
107 56 39.5 26
109 59 53 37
Optional specifications
Q R S T U
10 66 2.3 33.5 54
15 70 2.3 33.5 54
18 90 3.2 39 74
16 100 3.2 45 80
(mm)
E2 G H
Width across
20 33
flats 22
Width across
20 38
flats 24
Width across
26 49
flats 30
Width across
37 53
flats 36
With built-in silence
V W X Y
M4 x 0.7 Width across
－
3
Depth 6 flats 14
M4 x 0.7 Width across
― 3
Depth 6 flats 19
M5 x 0.8 Width across
― 4
Depth 6.5 flats 22
M6 x 1 Width across
56 6
Depth 8 flats 32
J
30
35
33
52
