English (GB) Installation and operating instructions
Original installation and operating instructions

Table of contents

1. General information . . . . . . . . . . . . . 5
1.1 Hazard statements . . . . . . . . . . . . . . 5
1.2 Notes . . . . . . . . . . . . . . . . . . . . . 5
2. Product introduction . . . . . . . . . . . . 6
2.1 Product description . . . . . . . . . . . . . . 6
2.2 Intended use . . . . . . . . . . . . . . . . . 6
3. Installation requirements . . . . . . . . . . 6
4. Electrical connection . . . . . . . . . . . . 6
4.1 Wiring diagram . . . . . . . . . . . . . . . . 7
5. Startup of the product. . . . . . . . . . . . 8
5.1 Starting and stopping the pump . . . . . . . 8
5.2 Resetting the thermal relay . . . . . . . . . . 8
6. Control functions . . . . . . . . . . . . . . 8
6.1 Operating panel . . . . . . . . . . . . . . . . 8
7. Technical data . . . . . . . . . . . . . . . . 8
8. Maintenance . . . . . . . . . . . . . . . . . 8
9. Service . . . . . . . . . . . . . . . . . . . . 8
10. Disposing of the product . . . . . . . . . . 9

1. General information

This appliance can be used by children
aged from 8 years and above and persons
with reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given super-
vision or instruction concerning use of the
appliance in a safe way and understand
the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not
be made by children without supervision.
Read this document before you install the
product. Installation and operation must
comply with local regulations and accepted
codes of good practice.

1.1 Hazard statements

The symbols and hazard statements below may
appear in Grundfos installation and operating
instructions, safety instructions and service
instructions.
DANGER
Indicates a hazardous situation which, if
not avoided, will result in death or serious
personal injury.
WARNING
Indicates a hazardous situation which, if
not avoided, could result in death or seri-
ous personal injury.
CAUTION
Indicates a hazardous situation which, if
not avoided, could result in minor or mod-
erate personal injury.
The hazard statements are structured in the following
way:
SIGNAL WORD
Description of the hazard
Consequence of ignoring the warning
• Action to avoid the hazard.

1.2 Notes

The symbols and notes below may appear in
Grundfos installation and operating instructions,
safety instructions and service instructions.
A blue or grey circle with a white graphical
symbol indicates that an action must be
taken.
A red or grey circle with a diagonal bar,
possibly with a black graphical symbol, in-
dicates that an action must not be taken or
must be stopped.
If these instructions are not observed, it
may result in malfunction or damage to the
equipment.
Tips and advice that make the work easier.
5
