The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user
to the presence of an insulated DANGEROUS VOLTAGE within the product's enclosure that may be of
sufficient magnitude to constitute an electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of impor-
tant operating and maintenance (servicing) instructions in the literature accompanying the appliance.
1U EIA 19" Rack Mount Chassis Dimensions (H x W x D approximate):
Rear
16 15
PICTURE GAIN PICTURE GAIN PICTURE GAIN PICTURE GAIN PICTURE
1.625"(41.3mm)
Front
0.75"
(19.1mm)
HubWayLD8D / HubWayLD16D
CAUTION: To reduce the risk of electric shock do not open enclosure.
There are no user serviceable parts inside.
Refer servicing to qualified service personnel.
1.625" x 19.125" x 8.5" (41.3mm x 486mm x 216mm)
14 13 12 11 10
GAIN PICTURE GAIN PICTURE GAIN PICTURE
Top and Bottom
1 2 3 4 CH 1-4 5
+ DATA --
1-8
Fig. 5
(ON)
Illuminated master power disconnect circuit breaker:
• OFF position Circuit breaker tripped – Switch not illuminated.
• RESET (ON) position – Switch illuminated.
9 8 7
GAIN PICTURE GAIN PICTURE GAIN PICTURE GAIN PICTURE GAIN PICTURE
17.625" (447.7mm)
6 7 8 CH 5-8
28VAC
OFF
24VAC
19.125" (486mm)
6 5 4 3 2
GAIN PICTURE GAIN PICTURE GAIN PICTURE
9 10 11 12 CH 9-12 13 14
+ DATA --
9-16
1
GAIN AC POWER
15 16 CH 13-16
28VAC
OFF
24VAC
