Troubleshooting
No or Poor Quality Picture (snow or noisy image)
• Verify that power is being supplied to all devices in the system and that they are powered on.
• Verify that all HDMI connections are not loose and are functioning properly.
• If transmitting 3D or 4K, verify that the HDMI cables used are 4K rated.
Troubleshooting Tips:
• WyreStorm recommends using a cable tester or connecting the cable to other devices to verify functionality.
Specifications
Audio and Video
Inputs
Outputs
Video Encoding
Encoding Data Rate
End to End Latency
Audio Formats
Video Resolutions (Max)
Supported Standards
Maximum Pixel Clock
Color Depth
Communication and Control
HDMI
IR
Push Button
Power
Power Supply
Max Power Consumption
Environmental
Operating Temperature
Storage Temperature
Maximum BTU
Dimensions and Weight
Rack Units/Wall Box
Height
Width
Depth
Weight
Regulatory
Safety and Emission
Note: WyreStorm reserves the right to change product specification, appearance or dimensions of this product at any time without prior notice.
Copyright © 2021 WyreStorm Technologies |
EXP-SW-0401-H2 Quickstart Guide | 210112
4x HDMI In: 19-pin type A
1x HDMI Out: 19-pin type A
HDMI | TMDS
NA
NA
2ch PCM | Multichannel: LPCM and up to DTS-X and Dolby Atmos
Resolution
1920x1080p @60Hz 12bit
1920x1080p @60Hz 16bit
3840x2160p @24Hz 10bit 4:2:0 HDR
3840x2160p @30Hz 8bit 4:4:4
3840x2160p @60Hz 10bit 4:2:0 HDR
4096x2160p @60Hz 8bit 4:2:0
4096x2160p @60Hz 8bit 4:4:4
DCI | RGB | HDR | HDR10 | Dolby Vision | HLG | BT.2020 | BT.2100
600MHz
12bit
HDCP 2.2 | EDID | DVI-D supported with adapter (not included)
1x IR Ext. Port
Front Panel Push Button
12V DC 1A
3.2W
0 to + 45°C (32 to + 113 °F), 10% to 90%, non-condensing
-20 to +70°C (-4 to + 158 °F), 10% to 90%, non-condensing
10.92 BTU/hr
<1U
16mm/0.62in
175mm/6.9in
66.2mm/2.6in
0.25kg/0.55lbs
CE | FCC | RoHS | EAC | RCM
wyrestorm.com
HDMI
15m/49ft
7m/23ft
5m/16ft
7m/23ft
3m/12ft
7m/23ft
3m/12ft
UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973)
