Linear Technology DC2283A Demo Manual page 8

DEMO MANUAL DC2283A
parts List
ITEM QTY REFERENCE
17 2 C39, C50
18 1 C43
19 1 C49
20 2 R1, R129
21 2 R2, R60
22 25 R3, R4, R15, R19, R39, R40, R42, R43, R45, R46,
R53, R91, R109, R113, R114, R116, R117, R127,
R132, R137, R140, R147, R148, R149, R156
23 14 R6, R7, R8, R10, R29, R30, R33, R34, R49, R50, R98,
R123, R124, R131
24 4 R9, R11, R12, R13
25 4 R14, R20, R135, R143
26 2 R18, R21
27 2 R22, R108
28 1 R23
29 6 R41, R44, R47, R48, R88, R90
30 2 R69, R70
31 4 R79, R80, R125, R130
32 1 R81
33 1 R89
34 1 R92
35 1 R93
36 1 R94
37 3 R95, R96, R107
38 1 R97
39 1 R99
40 1 R100
41 1 R102
42 1 R103
43 1 R104
44 1 R105
45 1 R106
46 2 R128, R150
47 2 R144, R155
48 1 R153
49 4 D1, D2, D3, D4
50 4 D5, D6, D8, D9
51 1 D7
52 2 D12, D13
53 4 L1, L2, L3, L4
54 1 L5
8
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
PART DESCRIPTION
CAP , 0603 100nF 20% 16V X7R
CAP , 0603 220pF 10% 50V X7R
CAP , 0603 47nF 10% 25V X7R
RES, 2010 0.002Ω 1% 1W
RES, 0603 1Ω 1% 1/10W
RES, 0603 0Ω JUMPER
RES, 0603 10kΩ 5% 1/10W
RES, 0603 2kΩ 5% 1/10W
RES, 0603 715Ω 1% 1/10W
RES, 0603 10Ω 1% 1/10W
RES, 0603 30.1kΩ 1% 1/10W
RES, 0603 1.96kΩ 1% 1/10W
RES, 2010 0Ω JUMPER
RES, 0603 10Ω 5% 1/10W
RES, 0603 200Ω 5% 1/10W
RES, 0603 127Ω 1% 1/10W
RES, 0603 2Ω 5% 1/10W
RES, 0603 3.3Ω 1% 1/10W
RES, 0603 154kΩ 1% 1/10W
RES, 0603 1MΩ 5% 1/10W
RES, 0603 20kΩ 5% 1/10W
RES, 0603 681kΩ 1% 1/10W
RES, 0603 301Ω 1% 1/10W
RES, 0603 82.5Ω 5% 1/10W
RES, 2512 0.01Ω 1% 1W
RES, VARIABLE 5k
RES, 0603 1kΩ 1% 1/10W
RES, 0603 118kΩ 1% 1/10W
RES, 0603 80.6kΩ 1% 1/10W
RES, 0603 4.99kΩ 1% 1/10W
RES, 0603 15.8kΩ 1% 1/10W
RES, 0603 3.57kΩ 1% 1/10W
DIODE, SCHOTTKY 30V, 100mA
LED, 0603 GREEN
LED, 0603 RED
DIODE, ULTRA LOW SCHOTTKY
RECTIFIER
IND, 0.25µH
IND, 68µH
MANUFACTURER/PART NUMBER
AVX, 0603YC104MAT2A
AVX, 06035C221KAT2A
AVX, 06033C473KAT2A
VISHAY, WSL20102L000FEA
VISHAY, CRCW06031R00FKEA
VISHAY, CRCW06030000Z0EA
VISHAY, CRCW060310K0JNEA
VISHAY, CRCW06032K00JNEA
VISHAY, CRCW0603715RFKEA
VISHAY, CRCW060310R0FKEA
VISHAY, CRCW060330K1FKEA
VISHAY, CRCW06031K96FKEA
VISHAY, CRCW20100000Z0EF
VISHAY, CRCW060310R0JNEA
VISHAY, CRCW0603200RJNEA
VISHAY, CRCW0603127RFKEA
VISHAY, CRCW06032R00JNEA
VISHAY, CRCW06033R30FKEA
VISHAY, CRCW0603154KFKEA
VISHAY, CRCW06031M00JNEA
VISHAY, CRCW060320K0JNEA
VISHAY, CRCW0603681KFKEA
VISHAY, CRCW0603301RFKEA
VISHAY, CRCW060382R5FKEA
VISHAY, WSL2512R0100FEA
BOURNS, 3386P-1-502-LF
VISHAY, CRCW06031K00FKEA
VISHAY, CRCW0603118KFKEA
VISHAY, CRCW060380K6FKEA
VISHAY, CRCW06034K99FKEA
VISHAY, CRCW060315K8FKEA
VISHAY, CRCW06033K57FKEA
CENTRAL SEMI, CMDSH-3 TR
WURTH ELEKTRONIK, 150060GS75000
WURTH ELEKTRONIK, 150060SS75000
NXP SEMI., PMEG2005AEL, 315
WURTH ELEKTRONIK, 744301025
SUMIDA, CDRH105RNP-680NC
dc2283af
