Connections - Eclipse AVN6610 Installation Manual

Genuine steering remote control terminal
G
Connect to the vehicle steering remote control.
※ Compatible vehicle models for installation : Vehicles with voltage detection-type steering remote control.
VTR output terminals
H
Connect to the monitor with video input.
Yellow : Video signal
VTR input terminals
I
Connect to the output wire of external video main unit such as a VTR.
Yellow : Video signal
Main unit connections
13 ACC ON/OFF power supply terminal (blue/white)
If you use this terminal to connect main unit such as an external amplifier, you can still hear the audio guidance
from the navigation system even when audio is turned off. Connect it to the control terminal for the external
amplifier or other main unit.
※ A popping noise may be heard when the engine is being started or the ignition switch is at the ON position, but
this is normal and is not the sign of a malfunction.
A
Back-eye camera external input terminal (4P)
Used with the Eclipse back-eye camera (sold separately).
B
Satellite tuner connection terminal (4P)
Connect a satellite tuner (sold separately) here.
E-LAN terminal (13P)
C
Connect to the E-LAN terminal of the CD changer, etc.
Ask your dealer for details.
White : Audio (left) signal
White : Audio (left) signal
- 8 -
Red : Audio (right) signal
Red : Audio (right) signal
