Eclipse AVN6610 Installation Manual page 7

Wire colors and connection points for connection wires
Never connect the power supply to the speaker wires (No.6 and No.7),
otherwise it will cause damage to the main unit.
Caution
B+ (Yellow)
1
Connect where power is constantly available, regardless of the ignition key's position.
ACC (Red)
2
Connect where the power comes on when the ignition is in the ACC position.
Illumination power supply (Orange/White)
3
Connect to where power comes on when the vehicle light switch is turned on.
4 Antenna power supply (Blue)
Connect to the automatic-antenna control terminal of the vehicle.
Control power supply (Blue/White)
5
Connect to the control terminal for the external amplifier, etc.
Front speaker output wires
6
Connect to the front speakers.
Rear speaker output wires
7
Connect to the rear speakers.
Cellular phone mute wire (Pink)
8
If you use a cellular telephone, connect it via the Audio Mute lead on the cellular telephone.
If not, keep the Audio Mute lead free of any connections.
9 Ground (Black)
Connect where good body grounding is available.
Vehicle speed pulse signal wire (Purple/White)
10
Connect to the vehicle speed pulse signal terminal.
Parking brake signal wire (Red/White)
11
Connect to the parking brake signal terminal.
Reverse signal wire (Green)
12
Connect the reverse signal output of the vehicle to this terminal.
D
Front line-out terminals
Connect to the RCA connector of an external amplifier.
E
Rear line-out terminals
Connect to the RCA connector of an external amplifier.
F
Line-out terminals (Sub-woofer)
This is used for non fader output. It can be used as a sub-woofer terminal if a separate amplifier with
a low bass filter is connected.
White: Left + White/Black:
Gray: Right + Gray/Black:
Green: Left + Green/Black:
Purple: Right + Purple/Black:
- 7 -
, , , ,
and
2 3 4
5 6
Left -
Right -
Left -
Right -
7
