Zaxcom RX-8

Allow Transmitter Remote Screens

ALLOW TX REMOTE:
SCREENS
When turned on two additional transmitter remote control menus will appear in the main menu. The first
menu gives the ability to remotely change the transmitters gain when the RX-8 is connected to a Camera
Link or IFB transmitter. The second menu is where the unit code for the receiver can be adjusted. The unit
code on the receiver must match the unit code on the transmitter that it is controlling.
Please note that this menu needs to be individually turned on for each side of the of the 414 receiver.
When transmitter remote control is turned on the frequency of the transmitter will automatically be
changed when the receive frequency on the RX-8 is adjusted.

RS422 Mode

RS422 MODE:
CAMERA LINK
• Camera Link - Used when the RX-8 is connected to a Camera Link or IFB via the RS422 port.
• USB (GUI) - For future GUI Bridge support.

LED On / Off

LEDS:
ON
This menu toggles On / Off the receiver status LED's.

Encryption Code Set

ID1: 000
The encryption menu is where the encryption is turned on and the code is set. The encryption code needs to
match the encryption code of the associated transmitters. If an encryption code is set on the transmitter the
transmitted audio will be encrypted and can only be listened to if the MRX has the same matching encryption
code entered. When the codes do not match, all that will be heard is white noise.
These two sets of numbers are formed into a single six-digit encryption code which provides a total of
16,777,216 possible combinations. For non-encrypted operations all six numbers should be set to 0.
Encryption can be set independently for each receiver side.

Adjusting the encryption code

Press the RECEIVER key to advance to the desired character.
1.
To change the designated character, press the INC or DEC key.
2.
Press the MENU key to exit.
3.
ON
ID0: 000
12
Extended Menu
