Dante Module On / Off

DANTE MODULE:OFF
This menu toggles power to the Dante module. Please note if the Dante module is on the receivers must be in
AES mode. This menu is only accessible in the A receiver for units that have Dante.

DB25 In-Out Mode

DB25 IN-OUT MODE:
RX 1-4 OUTPUTS
• RX 1-4 Outputs - The audio outputs from the A receiver (analog or AES outputs 1 thru 4) are on the DB25
connector.
• 8 AES Input to Dante - When the RX-8 is remoted 8 audio channels - via 4 AES pairs -can be inputted to the RX-
8 and sent via Dante as AES 9 thru 16.

DB25 Outputs

DB25 OUTPUTS:
RX 5-8 OUTPUTS
• RX 5-8 Outputs - The audio outputs from the B receiver (analog outputs 5 thru 8) are on the DB25
connector.
• 4 Analog Dante Out - When the RX-8 is remoted, 4 channels of analog audio received via Dante can be
outputted on the DB25. Time code can be optionally sent from the TC out BNC provided time code is sent
on audio channel 4 Via Dante.
