Element 14 Manual Original instructions
voltage, resulting in a loss of power and causing the motor to overheat. Use the information provided below to
determine the minimum wire size required in an extension cord. Only round jacketed cords listed by
Underwriter's Laboratories approval should be used.
For 110v supply: 3.5metres of 3 core x 1.5mm²
For230v supply: 26metres of 3 core x 1.5mm²
When working with the tool outdoors, use an extension cord that is designed for outside use. This is indicated
by the letters WA on the cord's jacket.
Before using an extension cord, inspect it for loose or exposed wires and cut or worn insulation.

9) MAINTENANCE

Note: Any maintenance must be carried out with the machine switched off and disconnected from the
mains/battery power supply.
Check that all safety features and guards are operating correctly on a regular basis. Only use this machine if all
guards/safety features are fully operational.
All motor bearings in this machine are lubricated for life. No further lubrication is required.
Use a clean, slightly damp cloth to clean the plastic parts of the machine. Do not use solvents or similar
products which could damage the plastic parts.
WARNING: Do not attempt to clean by inserting pointed objects through openings in the machine's casings
etc. The machine's air vents should be cleaned using compressed dry air. Excessive sparking may indicate the
presence of dirt in the motor or worn out carbon brushes.
If this is suspected have the machine serviced and the brushes replaced by a qualified technician with
Rotabroach recommended brushes.
CHIP COLLECTION TRAY
The chip collection tray should be emptied at regular intervals. We recommend that for efficiency purposes
the tray be emptied when it is approximately 60% full.
To check the Chip Collection Tray:
• Turn the locking lever to the horizontal position and withdraw the tray from the machine to check the
contents.
• Empty the contents of the tray into a suitable recycling bin.
• It may be necessary to wear a dust mask when emptying the chip collection tray.
• Replace the chip collection tray and return the locking lever to the vertical position to secure
the tray within the machine's base.
TRANSPORTATION/STORAGE
For ease and convenience, when transporting or storing the machine, the cutting head can be held in the
'down' position.
To hold the cutting head down:
• Lower the cutting head to its lowest position.
• Rotate the cutting head Locking Pin 1/4 of a turn and allow it to deploy to the 'locked down' position.
ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed of with household waste. Please recycle where facilities
exist. Check with your local authority or retailer for recycling advice.
15
