Spirit Commercial CVC800 Owner's Manual

Vertical climber
Hide thumbs

Advertisement

Quick Links

Download this manual
CVC800
Vertical Climber
OWNER'S MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the CVC800 and is the answer not in the manual?

Questions and answers

Related Manuals for Spirit Commercial CVC800

Summary of Contents for Spirit Commercial CVC800

  • Page 1 CVC800 Vertical Climber OWNER’S MANUAL...
  • Page 2 Spirit Fitness Spirit Fitness...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS PRODUCT REGISTRATION IMPORTANT SAFETY INSTRUCTIONS IMPORTANT ELECTRICAL INSTRUCTIONS IMPORTANT OPERATION INSTRUCTIONS CVC800 ASSEMBLY INSTRUCTIONS CONSOLE OPERATION PROGRAMMABLE FEATURES HEART RATE PROGRAM GENERAL MAINTENANCE MANUFACTURER’S LIMITED WARRANTY EXPLODED VIEW PARTS LIST Thank you for purchasing our product, please save these instructions. Please do not perform or attempt any customizing, adjustments, repair or maintenance that is not described in this manual.
  • Page 4 Congratulations on your new Vertical Climber and welcome to the Spirit Fitness family! Thank you for your purchase of this quality Vertical Climber from Spirit Fitness. Your new Vertical Climber was manufactured by one of the leading fitness manufacturers in the world and is backed by one of the most comprehensive warranties available.
  • Page 5 RECORD YOUR SERIAL NUMBER Please record the serial number of this fitness product in the space provided below. Serial Number: REGISTER YOUR PURCHASE The self-addressed product registration card must be completed in full and returned to Spirit Fitness. You can also go to http://www.spiritfitness.com/warranty under the Support tab to register online.

  • Page 6: Important Safety Instructions

    IMPORTANT SAFETY Keep children away from the Vertical Climber. There • are obvious pinch points and other caution areas that INSTRUCTIONS can cause harm. Keep hands away from all moving parts. WARNING • Never operate the Vertical Climber if it has a •...

  • Page 7: Important Electrical Instructions

    are intended only as exercise aids in determining your warranty. If you suspect the voltage is low, heart rate trends in general. contact your local power company or a licensed electrician for proper testing. NEVER expose this Wear proper shoes. High heels, dress shoes, sandals •...

  • Page 8: Important Operation Instructions

    GROUNDING INSTRUCTIONS to a 2-pole receptacle as shown below if a properly grounded outlet is not available. The temporary This product must be grounded. If the Vertical adapter should be used only until a properly Climber should malfunction or breakdown, grounded outlet, (shown below) can be installed by grounding provides a path of least resistance for a qualified electrician.
  • Page 9 immediately. Set your desired resistance level on the computer console and release the adjustment button. The computer will obey the command gradually. Use caution while participating in other activities while pedaling on your Vertical Climber; such as watching • television, reading, etc. These distractions may cause you to lose balance which may result in serious injury. Do not use excessive pressure on console control buttons.
  • Page 10 CVC800 PRE-ASSEMBLY UNPACKING TOOLS INCLUDED: 1. Cut the straps, then lift the box over the unit and unpack. ‰ 13/14m/m_Wrench ‰ 12/14m/m_Wrench 2. Carefully remove all parts from the carton and inspect for any ‰ Phillips Head Screw Driver damage or missing parts. If parts are damaged or missing, contact ‰...
  • Page 11 CVC800 STEP ZERO 1. Use L Allen Wrench (No.138) to remove two 3/8”x3/4” Socket Head Cap Bolts that hold the protective Side Back (No.23) onto the mounting plate on the Main Frame. Discard the bolts and set the Side Back (No.23) aside.
  • Page 12 CVC800 STEP ONE HARDWARE FOR STEP 1 PART TYPE DESCRIPTION HEX HEAD BOLT 3/8” x 3/4” HEX HEAD BOLT 3/8” x 3-3/4” 3/8” x 3/4” SOCKET HEAD CAP BOLT FLAT WASHER 3/8” x ø19 x 1.5T CURVED WASHER 3/8” x 23 x 2.0T SPLIT WASHER ø10 x 2T”...
  • Page 13 CVC800 STEP TWO HARDWARE FOR STEP 2 PART TYPE DESCRIPTION HEX HEAD BOLT 5/16” x 15mm FLAT WASHER 5/16” x 23 x 1.5T 3/8” x 3/4” HEX HEAD BOLT CURVED WASHER Ø3/8” x 23 x 2.0T 1. Take off the axle & screw from the Right Driving Assembly (No.19), install lower hole of Right Driving...
  • Page 14 CVC800 STEP THREE HARDWARE FOR STEP 3 PART TYPE DESCRIPTION HEX HEAD BOLT 3/8” X 2-1/4” CURVED WASHER 3/8” X 23 X 2.0T 3/8” X UNC16 X 2-1/2 HEX HEAD BOLT FLAT WASHER 3/8” x 19 x 1.5T NYLON NUT 3/8”...
  • Page 15 CVC800 STEP FOUR HARDWARE FOR STEP 4 PART TYPE DESCRIPTION PHILIPS HEAD SCREW M5 X 10MM SHEET METAL SCREW 3.5 x 12mm 1. Plug the Computer Cable (No.41) into Console Assembly (No.40). Install the Console Assembly on top of the mast of the Console Mast (No.2) (stuff rest cables into the mast tube), then firmly fasten 4 Tapping Screw (No.100) using the Screw Driver (No.137).

  • Page 16: Console Operation

    CVC800 CONSOLE OPERATION Spirit Fitness...
  • Page 17 Tablet Holder LCD Data Display Window Program Buttons Start, Stop, Level Up, Level Down, and Enter www.spiritfitness.com...
  • Page 18 POWER When the display is powered up, the all characters on the console will light up. The LCD Data Display Window will show the software version and the total time the climber has been used since it was new. After 3 seconds the console will go to the start-up display and your climber will be ready to use. QUICK START To begin working out in QUICK START mode, simply press the START key after the console has powered up.
  • Page 19 MANUAL The Manual program works as the name implies, manually. This means that you control the program yourself and not the computer. To start the Manual program follow the instructions below. 1. Press the Manual key, then press the ENTER key. 2.
  • Page 20 PRESET PROGRAMS The climber has five different programs that have been designed for a variety of workouts. These five programs have factory preset work level profiles for achieving different goals. HILL The Hill program simulates going up and down a hill. The resistance in the pedals will steadily increase and then decrease during the program.
  • Page 21 CARDIO The Cardio program is designed to increase your cardiovascular function and endurance. This is exercise for your heart and lungs. It will build up your heart muscle and increase blood flow and lung capacity. This is achieved by incorporating a higher level of exertion with slight fluctuations in work.

  • Page 22: Heart Rate Program

    HEART RATE PROGRAMS The old motto, “no pain, no gain”, is a myth that has been overpowered by the benefits of exercising comfortably. A great deal of this success has been promoted by the use of heart rate monitors. With the proper use of a heart rate monitor, many people find that their usual choice of exercise intensity was either too high or too low and exercise is much more enjoyable by maintaining their heart rate in the desired benefit range.
  • Page 23 If you enter your age during programming the console will perform this calculation automatically. Entering your age is used for the Heart Rate programs. After calculating your MHR you can decide upon which goal you would like to pursue. The two most popular reasons for, or goals, of exercise are cardiovascular fitness (training for the heart and lungs) and weight control.
  • Page 24 RATE OF PERCEIVED EXERTION There are more variables involved in how hard you should workout than just heart rate. Your stress level, physical health, emotional health, temperature, humidity, the time of day, the last time you ate and what you ate, all contribute to the intensity at which you should workout. The rate of perceived exertion (RPE), also know as the Borg scale, was developed by Swedish physiologist G.A.V.
  • Page 25 WEARING THE CHEST STRAP (SOLD SEPARTELY) 1. Attach the transmitter to the elastic strap using the interlocking button. 2. Adjust the strap as tightly as possible while ensuring it is still comfortable. 3. Position the transmitter with the logo centered in the middle of your torso facing away from your chest (some people must position the transmitter slightly left of center).
  • Page 26 ERRATIC OPERATION Caution! Do not use this Vertical Climber for Heart Rate programs unless a steady, solid Actual Heart Rate value is being displayed. High, wild, random numbers being displayed indicate a problem. Areas to look for interference which may cause erratic heart rate: 1.

  • Page 27: General Maintenance

    GENERAL MAINTENANCE Wipe down all areas in the sweat path with a damp cloth after each workout. If a squeak, thump, clicking or rough feeling develops the main cause is most likely one of two reasons: 1. The hardware was not sufficiently tightened during assembly. All bolts that were installed during assembly need to be tightened as much as possible.
  • Page 28 ENGINEERING MODE TThe console has built in maintenance/diagnostic software. The software will allow you to change the console settings from English to Metric and turn off the beeping of the speaker when a key is pressed for example. To enter the Maintenance Menu (may be called Engineering Mode, depending on version) press and hold down the Start, Stop and Enter keys keep holding the keys down for about 2 seconds and the Message Window will display “Engineering Mode”.
  • Page 29 VERTICAL CLIMBER WARRANTY EFFECTIVE July 22, 2021 Spirit Fitness warrants all its Vertical Climber parts for a period of time listed below from the date of retail sale, as determined by sale receipt, or in the absence of a sales receipt eighteen (18) months from the original factory shipping date.
  • Page 30 EXCLUSIONS This warranty does not cover the following: 1. CONSEQUENTIAL, COLLATERAL, OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING FROM ANY BREACH OF THIS WRITTEN OR ANY IMPLIED WARRANTY. NOTE: Some states do not allow the exclusion or limitation of incidental or consequential damages, so this limitation or exclusion may not apply to you.
  • Page 31 SERVICE Keep your bill of sale. Twelve (12) months from the date on the bill of sale or eighteen (18) months from the date of factory shipping as determined by the serial number establishes the labor warranty period should service be required. If service is performed, it is in your best interest to obtain and keep all receipts.
  • Page 32 Spirit Fitness...
  • Page 33 40-02 Console Inner Cover CVC800 Parts List 40-03 IPAD Plate Main Frame 40-04 IPAD Front Cover Strap Hold Down 40-05 150m/m_Receiver, HR Crank Arm 40-06 W/Receiver, HR Crank Axle 40-07 Console Display Board Linked Assembly (L) 40-08 Interface Board Linked Assembly (R)
  • Page 34 Right Slider Cover Ø3/8" × Ø19 × 1.5T_Flat Washer Slide Wheel Cover Ø8.5 × Ø26 × 2.0T_Flat Washer Pedal Foam (L) Ø5/16" × Ø23 × 1.5T_Flat Washer Pedal Foam (R) Ø5/16" × Ø23 × 3T_Flat Washer Beverage Holder Ø17 × Ø23.5 × 1.0T_Flat Washer Handlebar Cover (L) Ø5 ×...
  • Page 35 www.spiritfitness.com...
  • Page 36 800.258.4555 Spirit Fitness spiritservice@spiritfitness.com 3000 Nestle Road www.spiritfitness.com Jonesboro, AR 72401 CVC800 Owners Manual © 2021 All Rights Reserved Revision 7: 07.22.2021...
