Summary of Contents for Spirit Commercial ST800FT
- Page 1 Owner’s Manual Model No. 168129800FT ST800FT FUNCTIONAL TRAINER - Assembly - Operation - Adjustments - Parts - Warranty CAUTION: Read and understand this manual before operating unit Retain For Future Reference...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Product Registration ................... 2 Important Safety Instructions ..............3-5 Assembly Instructions ................. 6 Unpacking ....................7 Heavy Weight Stack .................. 13 Resistance Training Benefits and Tips ............14 General Maintenance ................15 Exploded View Diagram ................18 Parts List .................... -
Page 3: Product Registration
ST800FT Functional Trainer and welcome to the Dyaco Canada family! Thank you for your purchase of this Spirit ST800FT Functional Trainer from Dyaco Canada Inc. Your new ST800FT Functional Trainer was manufactured by one of the leading fitness manufacturers in the world and is backed by one of the most comprehensive warranties available. -
Page 4: Important Safety Instructions
BEFORE YOU BEGIN Thank you for choosing the SPIRIT ST800FT Functional Trainer. We take great pride in producing this quality product and hope it will provide many hours of quality exercise to make you feel better, look better, and enjoy life to its fullest. It's a proven fact that a regular exercise program can improve your physical and mental health. - Page 5 FACILITY SAFETY PRECAUTIONS • Read the Owner’s Manual carefully before assembling, servicing or using the equipment. • Securely anchor each machine to the floor using the anchor holes provided in each machine. NOTE: Dyaco Canada is not responsible for the actual anchoring of equipment. Consult with a professional contractor.
- Page 6 PROPER USAGE Use machine only as described in the manual. Failing to follow proper instructions may result in injury. • Do not lean against or pull on the framework or any component, whether machine is at rest or in use. Inappropriate or improper use may result in injury to users or third parties (bystanders).
- Page 7 SAVE THESE INSTRUCTIONS - THINK SAFETY! ST800FT ASSEMBLY INSTRUCTIONS To avoid possible damage to this ST800FT Functional Trainer, please follow these assembly steps in the correct order. Be sure to read your Assembly/Owner’s Guide before using your new ST800FT Functional Trainer.
-
Page 8: Unpacking
Cut the straps, then pull the staples away from the bottom half and lift the top half of the carton off of the bottom. The hardware is located in the holes of the associated tubes/brackets TOOLS REQUIRED / HARDWARE GUIDE ST800FT Button Head RATCHET WRENCH Cap Screw... -
Page 9: Assembly Instructions
ST800FT ASSEMBLY INSTRUCTIONS Assembly of the equipment takes professional installers approximately 2 hours. If this is the first time you have assembled this type of equipment, plan to spend more time. It is highly recommended to use professional installers to assemble the equipment. You may find it quicker, safer, easier to assemble with the assistance of another person as some components of the unit are large and heavy. - Page 10 ST800FT STEP TWO Attach the Transverse Beam (No. 8) to the Right Stand (No. 2) and the Left Stand (No. 1). Secure with: 4 M10 x 25 Hex Head Bolts (No. 59), 4 Spring Washers φ 10 (No. 73), 4 Washers φ11 x φ20 x 2 (No.
- Page 11 ST800FT STEP FOUR Slide the 2 Guide Bars (No. 10) into the holes at the base. Allow the Guide Bars to lean inward together toward the center of the machine - this will allow you to more easily slide on the necessary parts during this assembly step.
- Page 12 ST800FT STEP FIVE Repeat this step for both sides of the machine. Follow the diagram with the Cable Assembly (No. 26) through the framework as shown. Pay special attention to make sure the cable end with the bolt is connected at the “Finish” and the cable end with the loop is positioned at the “Start”...
- Page 13 ST800FT STEP SEVEN Attach the Hang Board (No. 11) to the two Cross Braces (No. 7) using: 4 M10 x 20 Button Head Cap Screw (No. 64), 4 Washers φ11 x φ20 x 2 (No. 76) Place the Accessories under the silhouette of their shape.
-
Page 14: Heavy Weight Stack
ST800FT HEAVY WEIGHT STACK Disassemble the Inner Shroud (No.17), two Guide Bars (No.10), 15 Weight Plates (No.51). Take away the two Support Frame (No.13), add 5 Weight Plates (No.51) to the Left stand (No.1). Repeat on the Right Stand (No.2). -
Page 15: Resistance Training Benefits And Tips
RESISTANCE TRAINING BENEFITS AND TIPS Always consult a physician before starting an exercise program. To be successful in your exercise program, it is important to develop an understanding of the basic principles of resistance training. Now that you have assembled your Dyaco Canada gym, it is only natural that you want to get started immediately. -
Page 16: General Maintenance
GENERAL MAINTENANCE For best performance, Dyaco Canada Inc. recommends the following maintenance schedule. Check the integrity and function of the following parts. Replace all worn components immediately. Your equipment comes with a commercial schedule decal. For in home use, please follow the maintenance schedule listed below: ROUTINE COMMERCIAL... - Page 17 GENERAL MAINTENANCE Links, Pull-Pins, Snap Hooks, Swivels, Weight Stack Pins: Check all pieces for signs of visible wear or damage. Check springs in snap hook and pull-pins for proper tension alignment. If the spring sticks or has lost its rigidity, replace it immediately. Upholstery: To ensure prolonged upholstery life and proper hygiene, all upholstered pads should be wiped down with a damp cloth after every workout.
- Page 18 Seat Sleeves, Guide Rods: Wipe down adjusting tubes with a dust free rag before applying lubricant. Lubricate seat sleeves and Guide Rods with a Silicon or Teflon based lubricant spray. Linear Bearings: Referring to the Owner’s Manual carefully disassemble the bearing from its housing and place a finger full of light grease (lithium, super lube, etc.) into the inside of the bearing.
-
Page 19: Exploded View Diagram
EXPLODED VIEW DIAGRAM Customer service: 1-888-707-1880 Dyaco Canada Inc 2020 Email: customerservice@dyaco.ca... -
Page 20: Parts List
PARTS LIST KEY NO PART NO DESCRIPTION Q’TY 9800FT01 Left Stand 9800FT02 Right Stand 9800FT03 Left Guide Bar 9800FT04 Right Guide Bar 9800FT05 Left Slip Frame 9800FT06 Right Slip Frame 9800FT07 Cross Brace 9800FT08 Transverse Beam 9800FT09 Dual Pulley Bracket 9800FT10 Guide Bar 9800FT11... - Page 21 KEY NO PART NO DESCRIPTION Q’TY 9800FT37 Aluminum Cap 25 9800FT38 Aluminum Ring 25 9800FT39 Spacer 9800FT40 Plug 9800FT41 Plug 9800FT42 Foot Cove 9800FT43 Shield Permanent Seat 9800FT44 Bumper 9800FT45 Mount Sleeve 9800FT46 Weight Bumper 9800FT47 Nylon Bumper 9800FT48 Nylon Spacer 9800FT49 Six Angle Flange Nut M12 9800FT50...
- Page 22 KEY NO PART NO DESCRIPTION Q’TY 9800FT74 Spring Washer 10 9800FT75 Arc Washer 10.5 x 21 x 1.8 9800FT76 Washer 11 x 20 x 2 9800FT77 Washer 9 x 16 x 1.5 Customer service: 1-888-707-1880 Dyaco Canada Inc 2020 Email: customerservice@dyaco.ca...
-
Page 23: Manufacturer's Limited Warranty
MANUFACTURER’S LIMITED WARRANTY Dyaco Canada Inc. warrants all its Functional Trainer parts for a period of time listed below, from the date of retail sale, as determined by a sales receipt. Dyaco Canada Inc.’s responsibilities include providing new or remanufactured parts, at Dyaco Canada Inc.’s option, and technical support to our independent dealers and servicing organizations. - Page 24 Please visit us online for information about our other brands and products manufactured and distributed by Dyaco Canada Inc. spiri�itness.ca solefitness.ca xterrafitness.ca dyaco.ca/products/everlast.html dyaco.ca/UFC/UFC-home.html spiri�itness.ca/johnnyg.html trainorsports.ca For more informa�on, please contact Dyaco Canada Inc. T: 1-888-707-1880 ⏐ 5955 Don Murie St., Niagara Falls, Ontario L2G 0A9 ⏐ sales@dyaco.ca...
