Operating Ranges - Delta Electronics 10GBASE-LRM SFP+ Optical Transceiver LCP-10G3B4EDR Specification Sheet

Operating Ranges (T
Multimode Fiber Type
62.5um MMF OM1
50um MMF OM2
50um MMF OM3
Optical Transmitter Characteristics (T
Parameter
Data Rate
Signaling speed variation from nominal.
Average Output Power
Wavelength
RMS Spectral Width at 1260nm
RMS Spectral Width between 1260nm and 1300nm
RMS Spectral Width between 1300nm and 1355nm
Extinction Ratio
Optical Modulation Amplitude
RIN OMA
20
Transmitter eye mask definition
{X1, X2, X3, Y1, Y2, Y3}
Notes:
1. Refer to the spectral limits curve in Figure 1.
DELTA ELECTRONICS, INC.
℃ ℃
= -5 to 70 )
c
Min.Modal
Opterating
Bandwidth
Range(m)
(MHz*km)
160/500 0.5 to 220
500/500 0.5 to 220
1500/500 0.5 to 220
= -5
C
Transmitter eye mask definition
Maximum Channel
Insertion Loss (dB)
1.9
1.9
1.9
℃ ℃
to 70 )
Symbol Min. Typ.
R 10.3125
P -6.5
avg
λ 1260
ER 3.5
OMA -4.5
RIN
{0.25, 0.40, 0.45, 0.25, 0.28, 0.40}
3
LCP-10G3B4EDR
Max. Unit Note
Gb/s
±100 ppm
0.5 dBm
1355 nm
2.4 nm
Figure 1 nm 1
4 nm
1.5 dBm
-128 dB/Hz
Revision: 0B
2008/9/5
