Delta Electronics 10GBASE-LRM SFP+ Optical Transceiver LCP-10G3B4EDR Specification Sheet page 13

Digital Diagnostic Monitoring Interface
Alarm and Warning Thresholds (2-Wire Address A2h)
#
Address
Bytes
00-01 2 Temp High Alarm
02-03 2 Temp Low Alarm
04-05 2 Temp High Warning
06-07 2 Temp Low Warning
08-09 2 Voltage High Alarm
10-11 2 Voltage Low Alarm
12-13 2 Voltage High Warning
14-15 2 Voltage Low Warning
16-17 2 Bias High Alarm
18-19 2 Bias Low Alarm
20-21 2 Bias High Warning
22-23 2 Bias Low Warning
24-25 2 TX Power High Alarm
26-27 2 TX Power Low Alarm
28-29 2 TX Power High Warning
30-31 2 TX Power Low Warning
32-33 2 RX Power High Alarm
34-35 2 RX Power Low Alarm
36-37 2 RX Power High Warning
38-39 2 RX Power Low Warning
40-45 16 Reversed
56-91 36 External Calibration Constants
92-94 3 Reversed
95 1 Checksum
96-97 2 Real Time Temperature
98-99 2 Real Time Supply Voltage
100-101 2 Real Time Tx Bias Current
102-103 2 Real Time Tx Optical Power
104-105 2 Real Time Rx Received Power
106-109 4 Reserved
110 1 Optional Status/ Control Bits
111 1 Reserved
112-119 8 Optional Set of Alarm and Warning
Notes:
1) T : Case Operating temperature
C
2) I : Operating current at room temperature. The min. setting current is 0 mA.
OP
3) P: Operating optical power of transmitter at room temperature.
4) P : Overload optical power of receiver
0
P : Sensitivity optical power of receiver
S
5) Byte 95 contains the low order 8bits of sum of bytes 0-94
DELTA ELECTRONICS, INC.
Name
-10 degree Celsius
13
LCP-10G3B4EDR
Value (Dec.)
85 degree Celsius
80 degree Celsius
-5 degree Celsius
3.6V
3.0V
3.5V
3.1V
Iop*2+20 mA
Iop-20 mA
Iop*2+10 mA
Iop-10 mA
P +3dB
P-3dB
P +2dB
P-2dB
P +2
0
P -2
S
P
0
P
S
www.deltaww.com
Unit Note
1
℃
Volt
mA 2
dBm 3
dBm 4
5
Revision: 0B
2008/9/5
