Delta Electronics 10GBASE-LRM SFP+ Optical Transceiver LCP-10G3B4EDR Specification Sheet page 14

State/ Control Bits
Byte Bit
110 7 Tx Disable State
110 6 Soft Tx Disable
110 5 Reserved
110 4 Rate Select State
110 3 Soft Rate Select
110 2 Tx Fault
110 1 LOS
110 0 Data_Ready_Bar
7)
Optional Set of Alarm and Warning
Byte Bit
112 7 Temp High Alarm
112 6 Temp Low Alarm
112 5 Vcc High Alarm
112 4 Vcc Low Alarm
112 3 Tx Bias High Alarm
112 2 Tx Bias Low Alarm
112 1 Tx Power High Alarm
112 0 Tx Power Low Alarm
113 7 Rx Power High Alarm
113 6 Rx Power Low Alarm
113 5-0 Reserved
116 7 Temp High Warning
116 6 Temp Low Warning
116 5 Vcc High Warning
116 4 Vcc Low Warning
116 3 Tx Bias High Warning
116 2 Tx Bias Low Warning
116 1 Tx Power High Warning
116 0 Tx Power Low Warning
117 7 Rx Power High Warning
117 6 Rx Power Low Warning
117 5-0 Reserved
Digital Diagnostic Monitor Accuracy
Parameter
Transceiver Temperature
Power Supply Voltage
TX Bias Current
TX Optical Power
RX Optical Power
Notes:
1) Temperature is measured internal to the transceiver
2)
Voltage is measured internal to the transceiver
DELTA ELECTRONICS, INC.
Name
Digital state of the Tx disable input pin
Read/ Write bit that allow software disable of laser
Rate Select State
Software Rate Select State
Digital state of the Tx fault output pin
Digital state of the LOS output pin.
NA
Name
Set when internal temperature exceeds high alarm level
Set when internal temperature is below low alarm level
Set when internal supply voltage exceeds high alarm level
Set when internal supply voltage is below low alarm level
Set when Tx Bias current exceeds high alarm level
Set when Tx Bias current is below low alarm level
Set when Tx output power exceeds high alarm level
Set when Tx output power is below low alarm level
Set when received power exceeds high alarm level
Set when received power is below low alarm level
Set when internal temperature exceeds high warning level
Set when internal temperature is below low warning level
Set when internal supply voltage exceeds high warning level
Set when internal supply voltage is below low warning level
Set when Tx Bias current exceeds high warning level
Set when Tx Bias current is below low warning level
Set when Tx output power exceeds high warning level
Set when Tx output power is below low warning level
Set when received power exceeds high warning level
Set when received power is below low warning level
Typical Value
± 3℃
± 3%
± 10%
± 1.5dB
± 3dB
14
LCP-10G3B4EDR
Description
Description
Note
1
2
Revision: 0B
www.deltaww.com
2008/9/5
