- Page 1 / Perfect Charging / Perfect Welding / Solar Energy Operating instructions KD Supply 2500 42,0426,0049,EN 002-09112021 Fronius prints on elemental chlorine free paper (ECF) sourced from certified sustainable forests (FSC).
-
Page 3: Table Of Contents
Safety Connecting the KD Supply 2500 to the cooling unit and power source Establishing a LocalNet connection between the KD Supply 2500 and the power source Connecting the KD Supply 2500 to the cold wire feeder, commissioning Connecting the KD Supply 2500 to the cold wire feeder, commissioning... -
Page 4: General
Thank you for the trust you have placed in our company and congratulations on buying this high-quality Fronius product. These instructions will help you familiarise yourself with the product. Reading the instructions carefully will enable you to learn about the many different features it has to offer. -
Page 5: Safety Symbols On The Rating Plate
Safety symbols The KD Supply 2500 has safety symbols on the rating plate. The safety symbols must on the rating NOT be removed or painted over. The symbols warn against operating the equipment in- plate correctly, which can cause serious injury and damage. - Page 6 US machine with additional warning notices...
-
Page 7: Controls, Connections And Mechanical Components
▶ Read and understand this document in full. ▶ Read and understand all safety rules and user documentation for this device and all system components. KD Supply 2500 - LocalNet X9.1 interface front Standard connection socket for the power source LocalNet X9.2 interface... -
Page 8: Fitting The Kd Supply 2500 To The Trolley
If the welding system is not equipped with an auto-transformer or a cooling unit, the KD Supply 2500 must be installed right at the bottom. If a cooling unit is present, fit it right at the bottom and place the KD Supply on top of... -
Page 9: Connecting The Kd Supply 2500 To The Cooling Unit And Power Source
Supply 2500 and cooling unit CAUTION! Risk of short circuit from kinked or damaged cables. This can result in serious personal injury and damage to property. ▶ When positioning the KD Supply 2500, ensure that the cables are not kinked. -
Page 10: Establishing A Localnet Connection Between The Kd Supply 2500 And The Power Source
Using two „Extrude-Tite“ screws, fasten the KD Supply to the fastening bars (2) on the front and back of the cooling unit Position the power source over the KD Supply 2500 using a suitable hoisting device Pull the power source connector as far as possible through the opening on the un-... -
Page 11: Connecting The Kd Supply 2500 To The Cold Wire Feeder, Commissioning
LocalNet X9.2 interface (front) or LocalNet X9.3 interface (rear) Commissioning Power for the KD Supply 2500 is supplied by the power source Connect the power source and the cold wire feeder using the interconnecting hosep- Connect the welding torch Carry out steps 1 and 2 as described in the power source and cold wire feeder oper-... -
Page 12: Care, Maintenance And Disposal
Care, maintenance and disposal General remarks Under normal operating conditions the KD Supply 2500 requires only a minimum of care and maintenance. However, it is vital to observe some important points to ensure the welding system remains in a usable condition for many years. -
Page 13: Technical Data
Technical data KD Supply 2500 Mains voltage 230 / 460 V Mains frequency 50 / 60 Hz Primary current I 2,4 / 1,3 A Secondary voltage U 55 V Secondary current I Protection IP 23 Measurements l x w x h 625 x 240 x 225 mm 24.61 x 9.45 x 8.86 in. - Page 16 SPAREPARTS ONLINE Fronius International GmbH Froniusstraße 1 4643 Pettenbach Austria contact@fronius.com www.fronius.com Under www.fronius.com/contact you will find the adresses of all Fronius Sales & Service Partners and locations.
