Hardware installation
4.1
Connection of BiSS Adaptor
Connect the BiSS Adaptor to the power supply. After that, connect the BiSS Adaptor to the PC by using a
USB-AB cable.
Figure 8: Cabling
ATTENTION: It is recommended to connect the power supply to the BiSS Adaptor all the time during
operation.
