Model 3050-TE
Moisture Analyzer
User Manual
Process Instruments
PN 305670901 Rev. Y
455 Corporate Boulevard
Configurator Version 2.2
Newark, DE 19702

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3050-TE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ametek 3050-TE

Summary of Contents for Ametek 3050-TE

  • Page 1 Model 3050-TE Moisture Analyzer User Manual Process Instruments PN 305670901 Rev. Y 455 Corporate Boulevard Configurator Version 2.2 Newark, DE 19702...

  • Page 2: Offices

    © 1998 AMETEK This manual is a guide for the use of the 3050-TE Moisture Analyzer. Data herein has been verified and validated and is believed adequate for the intended use of this instrument. If the instrument or procedures are used for purposes over and above the capabilities specified herein, confirmation of their validity and suitability should be obtained;...

  • Page 3: Table Of Contents

    Warning Labels ......................vii Electromagnetic Compatibility (EMC) ..............viii USE IN DIVISION 1 OR ZONE 1 HAZARDOUS LOCATIONS ......ix European Standards Information ...................x Chapter 1 3050-TE Moisture Analyzer Overview ........................1-1 Controller Communication ..................1-3 Verification ........................1-3 Gas Flow ......................... 1-3 Internal Timing ......................
  • Page 4 Status LEDs and Alarms ....................3-14 Chapter 4 Parameter Setup Setting Up System Parameters ..................4-1 Chapter 5 Remote Verification Chapter 6 Replacement Parts and Service Replacement Parts ......................6-1 Accessing the Analyzer ....................6-3 Chapter 7 Glossary of Terms iv | 3050-TE Moisture Analyzer...

  • Page 5: Safety Notes

    Safety Notes WARNINGS, CAUTIONS, and NOTES contained in this manual emphasize critical instructions as follows: An operating procedure which, if not strictly observed, may result in personal injury or envi- ronmental contamination. WARNING An operating procedure which, if not strictly observed, may result in damage to the equipment. CAUTION ...

  • Page 6: Warning Labels

    Achtung - Heiße Oberfläche Environmental Information (WEEE) This AMETEK product contains materials that can be reclaimed and recycled. In some cases the product may contain materials known to be hazardous to the environment or human health. In order to prevent the release of harmful substances into the environment and to conserve our natural resources, AMETEK recommends that you arrange to recycle this product when it reaches its “end of life.

  • Page 7: Electromagnetic Compatibility (Emc)

    Electromagnetic Compatibility (EMC) Read and follow the recommendations in this section to avoid performance variations or damage to the internal circuits of this equipment when installed in harsh electrical environments. CAUTION The various configurations of the 3050 should not produce, or fall victim to, electromagnetic disturbances as specified in the European Union’s EMC Directive.
  • Page 8 The approval applies to equipment without cable glands. When mounting the flameproof enclo- sure in the hazardous area, only flameproof cable glands or stopping boxes certified to EN50018 may be used. viii | 3050-TE Moisture Analyzer...
  • Page 9 Contents | ix...
  • Page 10 Resale items warranty is limited to the transferable portion of the original equipment manufacturer’s warranty to AMETEK. If you are returning equipment from outside the United State, a statement should appear on the documentation accompanying the equipment being returned declaring that the goods being returned for repair are American goods, the name of the firm who purchased the goods, and the shipment date.

  • Page 11: 3050-Te Moisture Analyzer

    The 3050 Moisture Analyzer is a smart sensor that measures trace concentrations of moisture in a process gas stream. At the heart of the 3050-TE Analyzer is a 3050- OLV, which has been modified for operation at moisture concentrations below 100 ppbv.
  • Page 12 The calibration data, which relates the moisture concentration of the gas stream to the measured frequency difference, are stored in an EEPROM within the QCM sensor module. Figure 1-2 3050 Analyzer Flow Diagram. 1-2 | 3050-TE Moisture Analyzer...

  • Page 13: Controller Communication

    Controller Communication All analyzer functions are controlled by a microprocessor housed within the smart sensor. Communication with the smart sensor is achieved through the following connections: • One analog input, 4 to 20 mA • One analog output, 4 to 20 mA, isolated. Can be either loop powered or powered by the analyzer.

  • Page 14: Internal Timing

    The sensor saver mode extents the life of the sensor, but provides slower response time. The analyzer updates every 2.5 minutes instead of 1 minute; however, the ana- lyzer still responds within specifications. Refer to analyzer specifications on page 2-1. 1-4 | 3050-TE Moisture Analyzer...
  • Page 15 (ethylene) natural gas Freon R12 Freon R22 Freon R114 Carbon Dioxide* * (special requirements - see AMETEK Service) Contact AMETEK Service with inquiries regarding other applications.  NOTE Overview...
  • Page 16 This page left intentionally blank. 1-6 | 3050-TE Moisture Analyzer...

  • Page 17: Chapter 2 Specifications

    SPECIFICATIONS Operating Environment -20 °C to 60 °C (-4 °F to 140 °F); Optional -40 °C (-40 °F) (Ambient temperature; Enclosed sample system) 90% RH maximum, noncondensing IEC Pollution Degree 2 IEC Installation Category II Maximum elevation 2,000 meters (6560 feet) Indoor/outdoor use Approvals and Certifications: UL/CSA General Safety Requirements...

  • Page 18: Alarms/Alerts

    0 to 1 bar (0 to 15 psig) Maximum Sample Inlet Pressure Requirement 138 kPa to 24150 kPa (20 psig to 3500 psig) to pressure reducer 138 kPa to 345 kPa (20 psig to 50 psig ) Maximum, pressure reducer to analyzer 2-2 | 3050-TE Moisture Analyzer...

  • Page 19: Exhaust Pressure

    Exhaust Pressure 0 to 1 bar (0 to 15 psi) gauge Sample Flow Requirement 150 SCCM, » 1 SLPM bypass flow available for increased response speed. Inlet Gas Temperature 0 °C to 100 °C (32 °F to 212 °F) Optimal results are obtained when inlet gas temperature is maintained at 60 °C (140 °F).
  • Page 20 This page intentionally left blank. 2-4 | 3050-TE Moisture Analyzer...

  • Page 21: Chapter 3 Installation

    A dryer (AMETEK Dryer PN 305400901S or equivalent) is required to dry reference gas to less than 0.01 ppmv. A dryer (AMETEK Dryer PN 305580901S or equivalent) is required to dry the zero gas to less than 0.01 ppmv for zeroing the 3050TE.

  • Page 22: Sample Pressure And Temperature Requirements

    Set back pressure regulator (if installed) to 0-15 psig. Open valve to dryer prior to closing the lid. Open sample valve. 3-2 | 3050-TE Moisture Analyzer...
  • Page 23 Figure 3-1 TE Sample System Flow Diagram. Installation & Start-Up...
  • Page 24 Sample Out Back Pressure Regulator (Optional) Sample In Pilot Valve Zero Module Instrument Air In Sample Out Sample In 3050 Dryer Zero Module Dryer 3050 Dryer Valve Figure 3-2 Sample System Components. 3-4 | 3050-TE Moisture Analyzer...
  • Page 25 Figure 3-3a Division 1 Installation Dimensions. Installation & Start-Up...
  • Page 26 Figure 3-3b Zone 1 Installation Dimensions. 3-6 | 3050-TE Moisture Analyzer...
  • Page 27 Figure 3-4 Typical Probe Installation. Figure 3-5 Heated Pressure Reduction Flow. Installation & Start-Up...
  • Page 28 Figure 3-6 Heated Pressure Reduction Installation. 3-8 | 3050-TE Moisture Analyzer...

  • Page 29: Electrical Connections

    Electrical Connections 1. Connect the 4 to 20 mA analog output and alarm contacts from the terminal block to user recording equipment as shown on wiring diagram figure 3-7. 2. Connect serial communication from analyzer to the PC being used for cus- tomer parameter setup.
  • Page 30 Figure 3-7 Interconnect Diagram. 3-10 | 3050-TE Moisture Analyzer...
  • Page 31 3. The 3050-OLV signal common is connected to earth ground. If the analog output is also grounded, the analog output will no longer be electrically isolated. Contact AMETEK if this situation occurs. CAUTION: Analyzer power must be removed when connecting or disconnecting the 4-20 mA signal.
  • Page 32 (maximum cable length 10m) 3050-OLV (type DB9M) (type DB9F) 3050-OLV (type DB9M) (type DB25F) Figure 3-9 RS-232 Wiring. 3-12 | 3050-TE Moisture Analyzer...
  • Page 33 Figure 3-10 RS-485 Cables, Multiple 3050’s. Installation & Start-Up 3-13...
  • Page 34 Figure 3-11 RS-485 to RS-232 Coversion for Host PC. 3-14 | 3050-TE Moisture Analyzer...

  • Page 35: Analyzer Start-Up

    Analyzer Start-up Turn on power source. Open main process shut-off valve. Adjust sample pressure between 20 and 50 psig. Dry Down Period Allow a minimum of 24 hours for the analyzer to dry down and stabilize. System alarms are normal during this period. When dry down is complete, cell frequency will be stable and the recorded data will have leveled off.
  • Page 36 An open data valid contact indicates verifica- NOTE tion is in process or an alarm condition. Red LED flashes 11 times if an invalid condition occurs. * Indicates System Alarm and Data Invalid Signal 3-16 | 3050-TE Moisture Analyzer...
  • Page 37 PC INTERFACE AMETEK 3050 Moisture Configurator Software The Configurator software provides a graphical user interface to set up parameters for either a single analyzer or multiple analyzers. Though you can set and view parameters for multiple analyzers using the ...
  • Page 38 Select AMETEK Serial for inital PC communication setup. Once communications with the analyzer are established, the Modbus serial can be selected if desired.  When changing from AMETEK Serial to Modbus Serial, the analyzer communications parameters must be changed before the computer serial NOTE port settings.
  • Page 39 Port Select the COM port on your computer where the connection to the analyzer is installed. Baud Rate Select the baud rate at which data will be transferred. Click if the analyzer is connected to an RS-232 port. RS-232 Port Click if the analyzer is connected to an RS-485 port.
  • Page 40 For initial setup of PC communication parameters, use the Setup button on the General tab. NOTE Configuring Multiple Analyzers Use the Device Communications tab to set the analyzer’s communication pa- rameters to agree with the PC settings when controlling analyzers in a daisy chain. 4-4 | 3050-TE Moisture Analyzer...
  • Page 41 Identifies the analyzer’s type of serial communication cable that is being used. Click if you are using a 2-wire cable. Two-Wire RS-485 Four-Wire RS-485 Click if you are using a 4-wire cable. Figure 4-3a. Device Communications setup screen for AMETEK Serial. PC Interface | 4-5...
  • Page 42 If communitcation is lost, recycle power on the analyzer and click Setup on the General Tab to change the PC Communications. NOTE P a rity S to p B its O d d E v e n N o n e N o n e 4-6 | 3050-TE Moisture Analyzer...
  • Page 43 Setup Tab Use the Setup tab to define analyzer parameters. Select the gas being sampled. Units Select the unit of measurement.  All values entered must be in the same unit of measure as selected. NOTE Figure 4-4. PC Serial Communications setup screen for Modbus.
  • Page 44 Check this box to enable the concentration alarm. Enter the high limit for the concentration alarm. High Limit Enter the low limit for the concentration alarm. Low Limit To Save settings on the Setup tab, click Apply. 4-8 | 3050-TE Moisture Analyzer...
  • Page 45 Verification Tab Use the Verification tab to schedule routine Zero. Verify Now Button Click to begin verification cycle now. Abort Button Click to terminate verification or zero. Zero Now Button Click to begin zero cycle now. Adjust Span After Verfy check box Checked The analyzer performs an span adjustment at the end of the zero cycle.
  • Page 46 You must also enter a time of day (1 through 24) in the Hour slot to begin the zero cycle. Monthly Enter the numeric (1 through 28) day of the month in the Day slot, 4-10 | 3050-TE Moisture Analyzer...
  • Page 47 Figure 4-8. Dryer and Moisture Generator code entry screens. and the time (1 through 24) in the Hour slot to begin zero cycle. Scheduled Zero Schedule routine Zeros by clicking the Daily, Weekly, or Monthly button No zero cycle will be done. Scheduling slots at the bottom of the Never box are not available.
  • Page 48 Flow Adjust is a utility designed to calibrate the internal flow meter inside the 3050 analyzer. In order to calibrate the flow meter, an external flow meter is needed to compare the flow reading on the analyzer with the actual flow. Figure 4-9. Status tab. 4-12 | 3050-TE Moisture Analyzer...
  • Page 49 Gas Factor Check Gas Factor if you run gas mixtures. Flow Meter Span Check Flow meter Span if you run pure gases. Figure 4-10a. Monitor tab. Flow Meter Reading To calibrate the internal flow meter: 1. Run a sample into the sample intake of the analyzer. 2.
  • Page 50 To discontinue test mode, press another tab. Test mode will automatically time out after 10 minutes of inactivity.  When the analyzer switches from test mode to online, the analyzer NOTE resets itself. Figure 4-11a. Flow Adjust Screen. 4-14 | 3050-TE Moisture Analyzer...
  • Page 51 Figure 4-11b. Flow Adjust Screen. PC Interface | 4-15...
  • Page 52 This page intentionally left blank. 4-16 | 3050-TE Moisture Analyzer...

  • Page 53: Remote Verification

    REMOTE VERIFICATION The analyzer can be commanded to initiate Zero and Verify functions re- motely via a 4-20 milliamp input into terminals 1 (+) and 2 (-) of TB3 (See Figure 3.7). The table below describes the analyzer response to a current input.
  • Page 54 This page intentionally left blank. 5-2 | 3050-TE Moisture Analyzer...

  • Page 55: Chapter 6 Replacement Parts And Service

    REPLACEMENT PARTS AND SERVICE Table 1 lists the replacement parts available for the Model 3050 Moisture Analyzer. Please contact the AMETEK Sales office (800-222-6789) for pricing and ordering information. Table 1 Model 3050-TE Sample System Replacement Part Part Description AMETEK Part Number...
  • Page 56 ASAP plans may be written to provide cover- vice Engineer to inspect the proposed analyzer location. age for a single analyzer or all of the AMETEK process The on-site charge for this visit can be deducted from analyzers at your facility.

  • Page 57: Accessing The Analyzer

    Accessing the Analyzer Remove hex heps nuts (4 Places) Figure 6-1 Hex Keps Nuts. Disconnect fittings using a 7/16” wrench. Figure 6-2 Tube Fittings. Replacement Parts & Service...
  • Page 58 Disconnect heated sample line connector. Figure 6-3 Sample Line Connector. Figure 6-4 Terminal Block Inside Enclosure. 6-4 | 3050-TE Moisture Analyzer...
  • Page 59 Exhaust Sample From Dryer Dryer 50 PSI Max Figure 6-5 Back of Analyzer. Replacement Parts & Service...
  • Page 60 This page intentionally left blank. Replacement Parts & Service...

  • Page 61: Glossary Of Terms

    GLOSSARY OF TERMS Annunciator Display A graphical representation of a panel annunciator on which alarm status of 3050 results are displayed. Address A decimal number that must be assigned to a Model 3050, when the host PC is communicating with multiple Model 3050 Moisture Analyzers.
  • Page 62 Model 3050 and used for verification of the analyzer’s proper operation. Personal computer Port The specific COM (serial) port of a host PC that will be used for RS-232 serial communication with a Model 3050. 7-2 | 3050-TE Moisture Analyzer...
  • Page 63 ppmv Parts per million by volume ppmw Parts per million by weight Process Pressure The pressure of the process gas, expressed in one of various possible units. Only required when engineering units of “dew- point” are selected. Resonance Frequency The frequency at which the QCM operates. RS-232 A serial communication protocol, in which the RS-232 serial output of a Model 3050 Analyzer may be directly connected to...
  • Page 64 A check of the accuracy of the Model 3050’s results, by refer- ence to an internally installed moisture standard. A verification cycle may be initiated manually, or at scheduled intervals. The analyzer’s calibration factors may be automatically adjusted if the “Calibrate after verify” box is checked. 7-4 | 3050-TE Moisture Analyzer...
  • Page 65 (PI-MBUS-300 RevJ). The Modbus protocol transmission mode imple- mented is Remote Terminal Unit (RTU) with the analyzer operating as a slave device. The AMETEK 3050 analyzer supports both RS485 and RS232 serial com- munication standards. The physical communication connection between a Model 3050 analyzer and a customer DCS\SCADA\PLC\DAS or a general-purpose computer is RS485 or RS232.
  • Page 66 Calculations, and possibly experi- mentation, are needed to attain optimal system operation. A-2 | 3050-TE Moisture Analyzer...
  • Page 67 ANALYZER MODBUS INTERFACE PARAMETERS A number of analyzer Modbus interface parameters need to be set up in order to establish communication with the Modbus master. These pa- rameters are accessed via the service port on the analyzer using a service program running on a PC.
  • Page 68 01 being returned. Illegal address exception code is returned when the requested address is outside the allowed range or writing to a read-only location. When the values to be written to holding registers are outside the appropriate ranges, exception code 03 is returned. A-4 | 3050-TE Moisture Analyzer...
  • Page 69 HOLDING REGISTERS Since the RAM space on the analyzers is limited and not every customer’s DCS\SCADA\DAS\PLC supports Modbus floating point value transfer, floating point values that are commonly accessed on a Model 3050 ana- lyzer are scaled and converted into integer values to load into Modbus registers for transmission.
  • Page 70 Electronics temperature input (AnalogEE= 70 Hex) counts Current flow reading (CurrentFlow= 8A Hex) sccm Maximum flow deviation (MaxFlowDev sccm = 8E Hex Special command (ModbusCommand= 93 Hex) Sensor pressure coefficient (Pressure1Span= 2 Hex) Sensor pressure offset (Pressure1Offset= 3 Hex) A-6 | 3050-TE Moisture Analyzer...
  • Page 71 T A B L E A -1 co n t. R E G D E F IN IT IO N U N IT S S C A L IN G A C C E S S S e ria l co m u n ica tio n m o d e (S e ria lM o d e = 2 6 H e x) S la ve a d d re ss (N o d e A d d re ss= 2 7 H e x) B a u d ra te (B a u d = 2 5 H e x) M o d b u s p ro to co l se ttin g (P a rityA n d S to p = 9 2 H e x)
  • Page 72 (C alT ype= 41 H ex) S oftw are revision num ber (V ersion= 47 H ex) R eset variable (S ystem R eset= 48 H ex) D efault m em ory flag (new F lag= 49 H ex) A-8 | 3050-TE Moisture Analyzer...
  • Page 73 T A B L E A -1 co n t. R E G D E F IN IT IO N U N IT S S C A L IN G A C C E S S R e a d o n ly e xce p t te st m o d e (A n a lo g In p u t= 4 E H e x) R e a d o n ly e xce p t te st m o d e (A n a lo g O u tp u t= 4 F H e x U se d in te st m o d e (R e a d T e stF ixtu re = 5 0 H e x) S a m p le = 0 ,g e n e ra to r = 1 ,re fe re n ce = 2...
  • Page 74 1 4 1 -1 6 1 C u sto m e r a n a lyze r n a m e (A n a lyze rN a m e = 2 8 H e x) strin g 1 6 2 -1 8 2 S e le cte d g a s (G a s= 2 A H e x) strin g A-10 | 3050-TE Moisture Analyzer...
  • Page 75 T A B LE A -1 cont. R E G D E F IN IT IO N U N IT S S C A LIN G A C C E S S 183-189 A nalyzer serial num ber (S erialN um ber= 44 H ex) string 190-196 S ensor serial num ber (C ellS erialN um ber= 45 H ex) string...
  • Page 76 Invalid Reading, Calibration Failure, Flow Alarm, Moisture Generator Date and Dryer Alarm. Register #25 is a ModbusCommand register. This register allows sending special commands to the 3050 analyzer as shown in the table below. A-12 | 3050-TE Moisture Analyzer...
  • Page 77 A L A R M N A M E S yste m S ta te B it N u m b e r o f b lin ks C o m m e n t M e m o ry F a ilu re B it 4 S yste m A la rm S e n so r F a ilu re...
  • Page 78 15 bytes Model Name =Analyzer Model Name are registers 213-220 12 bytes Serial Number =Analyzer Serial Number located in registers 183-189 4 bytes Version Number =S200 located in register #82 The byte count is 35 (23Hex). A-14 | 3050-TE Moisture Analyzer...
  • Page 79 3050 configurator software is compatible with MODBUS RTU as well. Switching protocols can be accomplished with the 3050 Configurator software or with the AMETEK “ProtocolSwitch” utility, which is discussed in the next section. All of the configuration parameters of the analyser can be modified by the “write one or multiple holding registers”...
  • Page 80 Enable hold the analog outputs at the last measured value, when the analyser is off-line to perform a verification cycle. ACTION. Write one holding register (function 06). Register address = 98 (holding register #40099). Value = 1(0-track during verify, 1-hold during verify). A-16 | 3050-TE Moisture Analyzer...
  • Page 81 Example 5: Setting the High-End of the Analog Output: TASK. Setup the analog output so that a moisture concentration of 100 ppm pro- duces a 20 ma current output. ACTION. Write one holding register (function 06). Register address = 45 (holding register #40046).
  • Page 82 Register address = 121,122. Value = -2.57E-11 ACTION 3. Set process pressure to fixed 150 kPa Write one holding register (function 06). Register address = 47 (holding register #40048). Value = 1500Hex (multiplied by the scaling factor of 10). A-18 | 3050-TE Moisture Analyzer...
  • Page 83 Write one holding register (function 06). Register address = 48 (holding register #40049). Value = 1500Hex (multiplied by the scaling factor of 10). Example 10: Setting Verification Schedule: TASK. Set the analyser to automatically trigger a verification cycle. For this example, the analyser will be set to perform a verification cycle on the 3 day of each month, at noon (12:00).
  • Page 84 This page intentionally left blank.
