Forest garden CSHSL66 Quick Start Manual

Charlbury 6' x 6' Summer House
IMPORTANT, RETAIN FOR FUTURE REFERENCE.
-READ CAREFULLY
Check all parts prior to assembly.
This building is pressure treated to ensure longevity of all timber
components and to protect against rot. This may leave a colour
difference on some parts that will even out as the moisture content
stabilises. This will not need additional treatment.
- Timber is a natural material. It will shrink and swell as a result of
varying moisture content.
- Please keep all plastic bags and small parts away from children
- This product must be built on a solid level base.
- The roof of this building is not a load bearing structure.
Help line: 0333 7777 089
Technical
Monday to Friday.
In line with your statutory rights, please check all parts prior to
Assembly, as assembly of damaged parts may be deemed to be
acceptance and this may affect the remedies you are entitled to. If the
product is not constructed in accordance with the instructions, or is
altered in any way (e.g. painted), the manufacturer cannot be held liable
for any resulting damage.
Fixing Pack (OASUM66PTFP)
Necked Barrel Bolt Turn Button
Qty 1 Qty 1
Tower Bolt Qty 1
(supplied with 6 x 20mm screws)
REQUIRED TOOLS :
(NOT SUPPLIED)
POZI DRIVE SCREWDRIVER
A
SASUM66PEPT
Plain End Qty 1
8.30 am to 5.00 pm
F
198510308
OSB Roof Qty 2
Not to Scale
K
L
Hinge
M
Qty 2
N
L' bracket
O
Qty 2
V
28120404PAII45PT 404mm Beading Qty 4
W
28120585PAII45PT 585mm Beading Qty 4
Forest Garden Ltd, Unit 288 Hartlebury Trading Estate, Hartlebury, Worcestershire, Dy10 4JB
SHARP KNIFE
TAPE MEASURE
FOR ROOFING FELT
SPIRIT LEVEL
B
SASUM66PSPT
Side Panel Qty 2
G H
PW888465
888mm Glaze Qty 2 584mm Glaze Qty 2
45281728PPT
45x28x1728mm Batten Qty 1
28280888PPT
28x28x888mm Batten Qty 4
28281985PPT
28x28x1985mm Batten Qty 2
2828904PAI70PT
28x28x904mm Angled Batten Qty 2
28281728PPT
28x28x1728mm Angled Batten Qty 1
MUST PRE DRILL
HAMMER

Parts List

C D
SASUM66DEPT SUM66FL
Door Panel Qty 1 Floor Qty 1
I J
FIN20010512PT
Finial Qty 2
PW584404
P
40121650PARPTR
40x12x1650mm Strip Qty 2
Q
80121030PPT
80x12x1030mm Barge Board Qty 4
R
45151710PT
45x15x1710mm Corner Strip Qty 4
S
40121667PPT
40x12x1667mm Strip Qty 4
T
40120736PPT
40x12x736mm Strip Qty 1
Beading
X
28120412PPT 28x12x412mm Beading Qty 2
Y
15120412PT 15x12x412mm Beading Qty 2
Important :
Assembly of this
building requires
a minimum of two
adults.
E
SDR651X1645PT
Door Qty 1
80121165PT
Barge Board Qty 4
85062
QTY 3
U
40120466PNPT
466mm Notched Strip.
Qty 2
