AYRSTONE AyrMesh IndoorAP Instructions

Start Here

Quickstart Guide - AyrMesh™IndoorAP

Ayrstone.com/support

Visit

for detailed instructions,

videos, slide shows, and a

troubleshooting guide

Check the contents

of the box:

• AyrMesh IndoorAP

• Antenna

• Mounting Bracket

• Mounting Screws

NOTE: AyrMesh IndoorAP must be connected to the Power Supply of one of our

outdoor products (AyrMesh Hub, Receiver, or Bridge), which must be installed

and working before you install the IndoorAP.

Mount the IndoorAP and the Power Supply indoors where it will stay dry.

We recommend mounting the IndoorAP up high on the wall for maximum range

and bandwidth inside your building.

Pull off the protective cover and screw the

antenna onto the IndoorAP.

Do not use tools and do not tighten

beyond finger-tight.

Table of Contents

Need help?

Do you have a question about the AyrMesh IndoorAP and is the answer not in the manual?

Page 1 • Antenna • Mounting Bracket • Mounting Screws NOTE: AyrMesh IndoorAP must be connected to the Power Supply of one of our outdoor products (AyrMesh Hub, Receiver, or Bridge), which must be installed and working before you install the IndoorAP.
Page 2 Attach to Power Supply Unplug the Ethernet cables from the outdoor product's power supply. Insert the IndoorAP to the “POE” side of the power supply and press until the IndoorAP “clicks” onto the power supply. (NOTE: you have to press pretty hard) Then plug the outdoor product's Ethernet cable back into the IndoorAP's PoE port.
