H-7082
FOLDING
DUMP TABLE
1. Place table upside down. Pull locking bracket to
release. (See Figure 1)
Figure 1
2. Unfold legs to upright position with casters facing
ceiling. (See Figure 2)
PAGE 1 OF 3
1-800-295-5510
uline.com
ASSEMBLY
Locking
Bracket
Figure 2
3. Rotate horizontal bar upward to slide onto pegs.
(See Figure 3)
Figure 3
Peg
4. Pull horizontal bar up to lock in place.
(See Figure 4)
NOTE: This requires a strong tug.
Figure 4
Para Español, vea página 2.
Pour le français, consulter la page 3.
0721 IH-7082
