dSCR Multiswitch
INSTRUCTION MANUAL
WSCR504 | WSCR506 | WSCR508
WSCR512 | WSCR516
www.whytetechnologies.com
In the interest of continuous improvement,
all specifications of products within this brochure are
subject to change without notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DSCR Series and is the answer not in the manual?

Questions and answers

Related Manuals for Whyte DSCR Series

Summary of Contents for Whyte DSCR Series

  • Page 1 dSCR Multiswitch INSTRUCTION MANUAL WSCR504 | WSCR506 | WSCR508 WSCR512 | WSCR516 www.whytetechnologies.com In the interest of continuous improvement, all specifications of products within this brochure are subject to change without notice.

  • Page 2: Table Of Contents

    CONTENTS Safety Precautions Guarantee General Description Product Description Technical Description Installation Instructions Commissioning the Multiswitch Example Configuration Specifications...

  • Page 3: Safety

    Do not over tighten the F connectors (finger tight only). GUARANTEE All Whyte products are guaranteed for a period of 4 years from the date of purchase against defects. Within this guarantee period, Whyte Technologies will repair or replace the faulty product. In the unlikely event, please return any faulty products to your dealer.

  • Page 4: General Description

    Seamless integration with conventional IRS Systems due to extremely low power consumption, low loss passive trunks and high gain TERR, make the new Series D range from Whyte the most versatile and easy to install dSCR Multiswitch range available. The Series D range can be directly conjoined with Series 5 conventional Multiswitches using the supplied F type couplers to seamlessly create Hybrid IRS Systems.

  • Page 5: Product Description

    PRODUCT DESCRIPTION TERR Sat A Sat B DC 12V WSCR508 REC 1 REC 2 8 Way dSCR Multiswitch TERR Gain REC 3 REC 4 TERR 0 dB REC 5 REC 6 -10dB -20dB SAT dSCR / Legacy Terrestrial Frequency 290 ~ 2340MHz Frequency 87 ~ 790MHz Min/Max Input...

  • Page 6: Technical Description

    TECHNICAL DESCRIPTION DC POWERING The Whyte Series D range can be Line Powered via any of the SAT input and output Trunk Lines. All SAT Trunk Lines are DC passing, whilst the TERR Trunk Line is DC isolated. The Multiswitches have an Auxiliary DC Input which will power the Multiswitch as well as provide power to the SAT input and output Trunk Lines when fitted with a Whyte PSU.
  • Page 7 STANDALONE MODE Series D Multiswitches can be used in stand alone mode when powered directly via the 18V Auxiliary Input by using a Whyte Power Supply Unit (sold separately). Any unused (open) SAT/TERR Trunk Outputs must be terminated using 75Ω...

  • Page 8: Installation Instructions

    INSTALLATION INSTRUCTIONS MOUNTING THE MULTISWITCH Select a suitable location to install the Multiswitch. Do not install the Multiswitch in damp, humid, hot or dusty areas. Using the screw slots on the Corner Brackets, secure the Multiswitch using the appropriate fixing screws and wall plugs to suit the relevant wall surface or cabinet.
  • Page 9 EARTH BONDING Earth bond the Multiswitch to the Earth Bonding Lug and/or the Earth Terminal Bars using minimum 4mm² Earth Bonding Cable. It is best practise to earth bond across all Multiswitches using a single unbroken Earth Bonding Wire. To achieve this, strip away 3cm of the insulation of a length of 4mm² Earth Bonding Wire.
  • Page 10 If in doubt, assume the current consumption of each LNB to be 200mA max (0.2A). Connect a suitable Whyte PSU to the Auxiliary 18V DC Input. If more than one PSU is required, the additional PSU(s) may be connected to any other Multiswitch, Launch Amplifier, Tap or Splitter within the system.

  • Page 11: Commissioning The Multiswitch

    USER BAND FREQUENCIES Sky UK EN50607 EN50494 FREQ 1680 1210 1280 1050 1420 1380 1115 1680 1480 1275 2040 1340 1030 1485 1080 1550 1130 1615 1530 1745 1580 1810 1630 1875 1730 1940 1780 1830 1880 1930 COMMISSIONING THE MULTISWITCH See Figure 4: 1.

  • Page 12: Example Configuration

    EXAMPLE CONFIGURATION Figure 4 WATS-517WB 4 X IF + TERR Launch Amp WATS-517WB TERR SAT: Freq Range 290~2340MHz | Gain 30dB | Slope 12dB±1dB | Max Output 112dBµV TERR: Freq Range 87~790MHz | Gain 24dB | Slope 8dB±1dB | Max Output 112dBµV Quattro and WB compatible TERR Sat A...
  • Page 13 EXAMPLE CONFIGURATION Hybrid IRS WATS-530WB 4 X IF + TERR Launch Amp WATS-530WB TERR SAT: Freq Range 290~2340MHz | Gain 30dB | Slope 12dB±1dB | Max Output 112dBµV TERR: Freq Range 87~790MHz | Gain 24dB | Slope 8dB±1dB | Max Output 112dBµV Quattro and WB compatible WSCR508 WSCR504...

  • Page 14: Specifications

    SPECIFICATIONS Pro-Tap MODEL WSCR504 Frequency Range SAT Wideband 290-2340MHz SAT Quatt ro 950-2150MHz TERR 87-790MHz Dual Satellite Recepti on SAT Wideband (2x WB LNB) Trunk Inputs (F-Type Female) 4 SAT + 1 TERR Trunk Outputs (F-Type Female) 4 SAT + 1 TERR Tap Outputs (F-Type Female) Gain -5dB ~ +25dB (AGC)
  • Page 15 WSCR504 | WSCR506 | WSCR508 | WSCR512 | WSCR516 WSCR508 WSCR512 WSCR516 WSCR506 290-2340MHz 290-2340MHz 290-2340MHz 290-2340MHz 950-2150MHz 950-2150MHz 950-2150MHz 950-2150MHz 87-790MHz 87-790MHz 87-790MHz 87-790MHz 4 SAT + 1 TERR 4 SAT + 1 TERR 4 SAT + 1 TERR 4 SAT + 1 TERR 4 SAT + 1 TERR 4 SAT + 1 TERR...
  • Page 16 Unit 1, Watermill Business Centre. Edison Road, Enfield. EN3 7XF Tel: 0330 999 1980 | info@whytetechnologies.com | www.whytetechnologies.com Copyright © Whyte Technologies February 2022...
