- Page 1 Mul ti s w it c h INSTRUCTION MANUAL WM508L | WM512L | WM516L | WM524L | WM532L www.whytetechnologies.com In the interest of continuous improvement, all specifications of products within this brochure are subject to change without notice.
-
Page 2: Table Of Contents
CONTENTS Safety Precautions Guarantee General Description Product Description Technical Description Installation Instructions Example Configuration Specifications... -
Page 3: Safety
Do not over tighten the F connectors (finger tight only). GUARANTEE All Whyte products are guaranteed for a period of 4 years from the date of purchase against defects. Within this guarantee period, Whyte Technologies will repair or replace the faulty product. In the unlikely event, please return any faulty products to your dealer. -
Page 4: General Description
Multiswitch is compatible with Quad or Quattro LNB’s and comes in a range of models including 8, 12, 16, 24 and 32-Way output. The Whyte Series 5 Lite range is RED compliant and has a built in selectable 4G/5G filter for excellent rejection of LTE signals. -
Page 5: Product Description
PRODUCT DESCRIPTION 0dB 10dB TERR Gain TERR 12V ON OFF TERR Filter WM516L Quad & Quattro LNB Compatible Multiswitch Freq Range TERR 87~790 MHz Freq Range SAT 950~2150 MHz Gain TERR 10dB/0dB±2dB Gain SAT 2±2dB Max Output TERR 95dBµV Max Output SAT 95dBµV LNB Power 500mA Max... -
Page 6: Technical Description
TECHNICAL DESCRIPTION Whyte Series 5 Lite Multiswitches are compatible with Quad and Quattro LNB’s. The inputs are colour coded for ease of installation which is especially useful when using a Quattro LNB. For convenience, existing satellite dishes which are already fitted with a Quad LNB may be used, whereby the drop cables can be connected to the SAT inputs in no particular order. - Page 7 Earth bond the Multiswitch to the Earth Bonding Lug using minimum 4mm² Earth Bonding Cable. Make sure that the Earth Bonding Cable is connected directly to the building’s PME (Protective Multiple Earthing) point. Matching Whyte Technologies Earth Bonding bars for your Multiswitch are available from Whyte Technologies distributors.
- Page 8 CONNECTING THE POWER SUPPLY UNIT (PSU) The PSU must be fixed to the relevant wall surface using the appropriate fixings. Connect the DC F-type lead to the 18V DC Input of the Multiswitch. Once all connections have been made, connect the plug to a 240V AC (110V AC) socket to power up the Multiswitch.
-
Page 9: Example Configuration
EXAMPLE CONFIGURATION WM516L PSU-08A SAT1 SAT2 FM DAB FM DAB SAT1 SAT2 FM DAB FM DAB... -
Page 10: Specifications
SPECIFICATIONS: WM508L MODEL WM508L Frequency Range 950-2150MHz TERR 87-790MHz 4G/5G Switch RED Compliant Input (F-Type Female) 4 SAT + 1 TERR Tap Outputs (F-Type Female) Gain 2±2dB TERR (switchable gain) 10dB/0dB±2dB Return Loss SAT Trunk Input >11dB TERR Trunk Input >8dB... - Page 11 WM512L | WM516L | WM524L | WM532L WM512L WM516L WM524L WM532L 950-2150MHz 950-2150MHz 950-2150MHz 950-2150MHz 87-790MHz 87-790MHz 87-790MHz 87-790MHz 4 SAT + 1 TERR 4 SAT + 1 TERR 4 SAT + 1 TERR 4 SAT + 1 TERR 2±2dB 2±2dB 2±2dB 2±2dB...
- Page 12 Unit 13, Watermill Business Centre. Edison Road, Enfield. EN3 7XF Tel: 0330 999 1980 | info@whytetechnologies.com | www.whytetechnologies.com Copyright © Whyte Technologies June 2020 - Rev.2...
