- Page 1 5 W i r e Mu l t i s w i t ch INSTRUCTION MANUAL WM508 | WM512 | WM516 | WM524 | WM532 www.whytetechnologies.com In the interest of continuous improvement, all specifications of products within this brochure are...
- Page 2 Example Configuration GUARANTEE Specifications All Whyte products are guaranteed for a period of 4 years from the date of purchase against defects. Within this guarantee period, Whyte Technologies will repair or replace the faulty product. In the unlikely event, please return any faulty products to your dealer.
- Page 3 GENERAL DESCRIPTION PRODUCT DESCRIPTION Whyte Series 5 Multiswitches are high gain, universally flexible and are designed to be used in small, medium and large Integrated Reception Systems (IRS). The Multiswitches come fitted with a 4G/5G selection switch for rejection of LTE interference and are compliant with the RED Directive. Series 5 Multiswitches are line powered but can also be used as Standalone Multiswitches when powered directly via the18V Auxiliary Input.
- Page 4 The Multiswitches come fitted with a DC Input which enables the Multiswitch in damp, humid, hot or dusty areas. Using the screw slots on the Multiswitch to be used in Standalone Mode when fitted with a Whyte PSU. Corner Brackets, secure the Multiswitch using the appropriate fixing screws This will power the Multiswitch as well as provide voltage to the HL &...
- Page 5 REC4 REC6 REC8 REC10 REC12 REC14 REC16 DC IN 18V AUXILIARY DC OUT 18V Figure 2 Whyte Multiswitch WM516 Freq Range TERR 47~790 MHz Freq Range SAT 950~2150 MHz Gain TERR DC 12V Gain SAT 10dB 85dBµV Max Output TERR Max Output SAT 100dBµV...
- Page 6 If in doubt, assume the current consumption of each LNB to be 200mA max (0.2A). Connect a suitable Whyte PSU to the Auxiliary 18V DC Input. If more than one PSU is required, the additional PSU(s) may be connected to any other Multiswitch, Launch Amplifier, Tap or Splitter within the system.
- Page 7 SPECIFICATIONS WM508 | WM512 WM516 | WM524 | WM532 MODEL WM508 | WM512 WM516 WM524 WM532 Frequency Range 950-2150MHz 950-2150MHz 950-2150MHz 950-2150MHz TERR 87-790MHz 87-790MHz 87-790MHz 87-790MHz 4G/5G Switch Input (F-Type Female) 4 SAT + 1 TERR 4 SAT + 1 TERR...
- Page 8 Unit 13, Watermill Business Centre. Edison Road, Enfield. EN3 7XF Tel: 0330 999 1980 | info@whytetechnologies.com | www.whytetechnologies.com Copyright © Whyte Technologies June 2020...
