CHIEF RMF Specification Sheet

FEATURES
integrateD LateraL Shift
1
Reposition mount 2.25" (57 mm) left or
right after installation for ultimate
positioning flexibility.
excLuSive gLiDe Lock™ Latch
2
tool-less locking feature saves time and
effectively secures flat panel to wall mount.
raPiD LeveLing™
3
Hands-free leveling of mount on wall.
SPECIFICATIONS
Depth from Wall 1.63" (41 mm)
Lateral Shift 2.25" (57 mm)
Dimensions* 10.25" x 20" x 1.63"
(HxWxD) (260 x 508 x 41 mm)
Color Black
Weight Capacity 100 lbs (45.4 kg)
* Dimensions don't include interface bracket
TECHNICAL DRAWINGS
20"
(508 mm)
17.92" (455 mm) max.
3.71" (94 mm) min.
8"
(203 mm)
CliCk
www.chiefmfg.com
rmf 26 - 40" Rail mount
™
WHAT YOU NEED TO KNOW
uniVersal fixed mount
The maximum width between your mounting holes must be less than 17.9"
(455 mm) and the maximum height must be less than 9.25" (235 mm) to
ensure compatilbility of this mount.
installation
Includes all mounting hardware.
10.25"
(260 mm)
1.63"
(42 mm)
For a complete list of flat panel mount accessories see page 69.
CAll
800.582.6480
fixed wall mounts
3
1
RECOMMENDED ACCESSORIES
PaC515 New Construction
n
Pre-Wire Box
PaC520 Multiple Option New
n
Construction Pre-Wire Box
PaCPC1 Power Filter
n
2
