Installation Instructions DISCLAIMER CSAV, Inc., and its affiliated corporations and subsidiaries (collectively, "CSAV"), intend to make this manual accurate and complete. However, CSAV makes no claim that the information contained herein covers all details, conditions or variations, nor does it provide for every possible contingency in connection with the installation or use of this product.
Page 3
MFC, PFC Series Installation Instructions DIMENSIONS [177]...
Page 4
Installation Instructions LEGEND Tighten Fastener Apretar elemento de fijación Befestigungsteil festziehen Apertar fixador Serrare il fissaggio Bevestiging vastdraaien Serrez les fixations Loosen Fastener Aflojar elemento de fijación Befestigungsteil lösen Desapertar fixador Allentare il fissaggio Bevestiging losdraaien Desserrez les fixations Phillips Screwdriver Destornillador Phillips Kreuzschlitzschraubendreher Chave de fendas Phillips...
Installation Instructions TOOLS REQUIRED FOR INSTALLATION (Included) PARTS A (1) (left) K (1) 3/16" 3/16" B (1) (right) C (2) F (1) G (1) Only L (4) M (4) 5/16-18 x 2-3/4" 5/16-18 x 3/4" MFC, PFC Series D (4) E (1) J (1) 3/16"...
Page 6
MFC, PFC Series ASSEMBLY CAUTION: Attachment holes may be damaged if a power drill is used to insert button head cap screws. Screws should first be inserted and turned BY HAND with the hex key or with a handheld screwdriver BEFORE using the hex head drill bit and power drill to complete the attachment.
Page 7
Installation Instructions Attaching Display to Cart WARNING: EXCEEDING MAXIMUM WEIGHT CAPACITY MAY LEAD TO SERIOUS PERSONAL INJURY OR DAMAGE TO EQUIPMENT! It is the installer’s responsibility to ensure the total amount of weight placed on the cart does not exceed 125 lbs (56.70 kg) for the MFC, and 200 lbs (90.72 kg) for the PFC.
Page 8
MFC, PFC Series Tilting Display The display can be tilted up to 15 from a straight upright position. Turn knob counterclockwise on back of head assembly to loosen the tilt. (See Figure 9) Figure 9 Tilt display as desired, to a maximum of 15 or backward.
Page 9
Installation Instructions Figure 11 Always place cart on level surface. Always lock the wheels when the cart is not moving. Check and tighten the hex nuts on the casters occasionally. (See Figure 12) These should be checked especially after use on uneven ground. Figure 12 Removing Display from Cart Remove bolt or padlock from faceplate (if used).
Page 10
MFC, PFC Series 8809-000038 Rev.B 2007 Chief Manufacturing www.chiefmfg.com 06/07 USA/International A 8401 Eagle Creek Parkway, Savage, MN 55378 P 800.582.6480 / 952.894.6280 F 877.894.6918 / 952.894.6918 Europe A Fellenoord 130 5611 ZB EINDHOVEN, The Netherlands P +31 (0)40 2668620...
