I N S T A L L A T I O N
Plasma Presenters Dual Display
Video Conferencing Cart (PPD-Series)
The PPD is a highly functional video conferencing solu-
tion. The cart provides agile mobility for two Large Flat
Panel Displays, side-by-side, with a combined weight of
up to 200 pounds. Optional equipment shelves and video
conferencing accessory shelves can be easily added for
a complete system.
Using Chief's exclusive ClickConnect™ Mounting Sys-
tem for easy installation, the cart provides stable mount-
ing, quick release and optional security. Additionally, its
streamline shape eliminates trip hazards and allows the
display to roll smoothly up to a conference table
Large swivel casters with lock brakes, pitch adjustment,
and cable management make the cart user friendly.
BEFORE YOU BEGIN
• CAUTION: To prevent damage to the cart, which could affect or void the Factory warranty, thoroughly
study all instructions and illustrations before you begin to install or operate the unit. Pay particular atten-
tion to the "Important Warnings and Cautions" on Page 2.
• The maximum weight to be installed on the PPD is 200 pounds (90.72 Kg).
• If you have any questions about this assembly, contact Chief Manufacturing at 1-800-582-6480 or 952-894-6280.
Chief® and ClickConnect™ are trademarks of Milestone AV Technologies. All rights reserved.
Ch ief Manufacturing, a d ivision of Milestone AV Technologies
8401 Eagle Cr eek Pa rkway, Savage, MN 55378
P: 800 .582.6480 / 952.894.62 80 F: 877.894.6918 / 952.894.6918
I N S T R U C T I O N S
8809-000004 Rev E
©2008 Milestone AV Technologies
www.chiefmfg.com
05-08

Advertisement

loading
Need help?

Need help?

Do you have a question about the PPD Series and is the answer not in the manual?

Questions and answers

Summary of Contents for CHIEF PPD Series

  • Page 1 • The maximum weight to be installed on the PPD is 200 pounds (90.72 Kg). • If you have any questions about this assembly, contact Chief Manufacturing at 1-800-582-6480 or 952-894-6280. Chief® and ClickConnect™ are trademarks of Milestone AV Technologies. All rights reserved.
  • Page 2 Installation Instuctions PPD-Series IMPORTANT WARNINGS and CAUTIONS! WARNING: A WARNING alerts you to the possibility of serious injury or death if you do not follow the instructions. CAUTION: A CAUTION alerts you to the possibility of damage or destruction of equipment if you do not follow the corresponding instructions.
  • Page 3: Table Of Contents

    Installation Instuctions PPD-Series CONTENTS INSPECT PARTS BEFORE ASSEMBLY INSPECT PARTS BEFORE ASSEMBLY ....3 • Refer to Table 1 on page 4 and “PARTS” on page 4. Carefully inspect the parts for shipping damage. OPTIONAL ACCESSORIES ........3 • If any damage is apparent, call your carrier claims TOOLS REQUIRED FOR INSTALLATION ....
  • Page 4: Parts

    Installation Instuctions PPD-Series PARTS Table 1: Parts List DESCRIPTION DESCRIPTION CASTERS, Front (No Locks) LEG, Right CASTERS, Rear (Locking) SCREW, Cap, Button head, 1/4 20 x 5/8” PLUG, Cap (hard plastic - use with base) SCREW, Cap, Button head, 5/16-18 x 3/4” PLUG, Cap (slip on vinyl - use with legs) WASHER, 1/4”...
  • Page 5 Installation Instuctions PPD-Series PARTS (CONT’D)
  • Page 6: Assemble Cart

    Installation Instuctions PPD-Series ASSEMBLE CART NOTE: Read all instructions before assembly. Also, (10) refer to Table 1 on page 4 and “PARTS” on Front Casters page 4 for the numbers shown in parenthe- sis ( ). 1. Place base (100) upside down (see Figure 1). (20) a.
  • Page 7 Installation Instuctions PPD-Series ASSEMBLE CART (CONT’D) 6. Adjust tilt head (70) to desired tilt by slightly loosen- ing four 1/4-20x5/8” button head cap screws (130) securing tilt head spreaders (90), adjust tilt head to desired angle (0º to 7-1/2º), and tighten four 1/4-20x5/8”...
  • Page 8: Mount Plasma Displays On Cart

    Installation Instuctions PPD-Series MOUNT PLASMA DISPLAYS ON CART 1. Measure the distance from the center of your display to its outermost edge. NOTE: Make sure to leave some space between displays when mounted. 2. Using the measurement found in Step 1 and the faceplate (50) as a template, measure from the cen- ter of the dual screen mounting bracket (80) to find the correct mounting holes for your application (see...
  • Page 9 Installation Instuctions PPD-Series MOUNT PLASMA DISPLAYS ON CART (CONT’D)To install display: WARNING! Make sure cart wheels are locked before installing the display to the cart! 4. While supporting both sides of display, align four To use as a mounting buttons on display or interface bracket more permanent lock, with four mounting holes in faceplate.
  • Page 10 Installation Instuctions PPD-Series...
  • Page 11 Installation Instuctions PPD-Series...
  • Page 12 Installation Instuctions PPD-Series...
