- Page 1 5G CPE UF51 Quick Start Guide Milesight IoT...
- Page 2 The related documents are available on Milesight website: https://www.milesight-iot.com Declaration of Conformity UF51 is in conformity with the essential requirements and other relevant provisions of the CE, FCC, and RoHS. For assistance, please contact Milesight technical support: Email: iot.support@milesight.com...
-
Page 3: Table Of Contents
Contents 1. Packing List..............................4 2. Hardware Introduction..........................5 2.1 Overview...............................5 2.2 Dimensions............................5 2.3 Serial & IO & Power Pinouts......................6 2.4 LED Indicators............................. 6 2.5 Reset Button............................7 3. Power Supply..............................7 4. Hardware Installation........................... 7 4.1 SIM Card Installation.......................... 7 4.2 Waterproof Cover &... -
Page 4: Packing List
1. Packing List Before you begin to install the UF51 5G CPE, please check the package contents to verify that you have received the items below. 1 × UF51 Device 1 × PoE Injector 1 × Mounting Bracket 1 × Ethernet Cable 4 ×... -
Page 5: Hardware Introduction
2. Hardware Introduction 2.1 Overview LED Indicator Area STATUS: Power & System Indicator 5G: Cellular Indicator Waterproof Connector SIM Slot Reset Button Vent Plug LAN2 Port Bracket Mounting Screws Serial & IO & Power Interface LAN1/WAN Port (PoE PD) 2.2 Dimensions (mm) -
Page 6: Serial & Io & Power Pinouts
2.3 Serial & IO & Power Pinouts RS232 Power Description /RS485 Digital Input Ground Negative Positive (9-48V) Common Ground Digital Output RS232-RXD RXD/B RS485-B RS232-TXD TXD/A RS485-A 2.4 LED Indicators Indication Status Description The power is switched off Power & Orange Static: The system is startup STATUS... -
Page 7: Reset Button
Both power supplies can’t be used at the same time. PoE Supply: Follow the below picture to provide power supply via PoE injector. Besides, UF51 can also be powered by PoE switch. DC Supply: Connect the DC power cable to terminal block, then connect the terminal block to DC interface to power the device. -
Page 8: Waterproof Cover & Ethernet Cable Installation
4.2 Waterproof Cover & Ethernet Cable Installation If you need to use UF51 outdoors, the waterproof cover and cable gland should be installed under the bottom of the device. A. Install the rubber ring into the bottom of the device. Note that the round part needs to face the gap of bottom when installing, otherwise it may cause waterlogged. -
Page 9: Device Installation
4.3 Device Installation UF51 supports multiple installation methods like desktop, wall mounting, pole mounting, etc. Before you start, make sure that your SIM card has been inserted and all cables have been installed. Note: Do not connect device to power supply or other devices when installing. -
Page 10: Pole Mounting
4.3.3 Pole Mounting Preparation: mounting bracket(with 2 screws), hose clamps and other required tools. A. Loosen the hose clamp by turning the locking mechanism counter-clockwise. B. Straighten out the hose clamp and slide it through the rectangular rings in the mounting bracket, wrap the hose clamp around the pole. -
Page 11: Login The Web Gui
5. Login the Web GUI UF51 provides web-based configuration interface for management. If this is the first time you configure the device, please use the default settings below: Username: admin Password: password 5.1 Wireless Access A. Enable Wireless Network Connection on your computer and search for access point “Router_******”... -
Page 12: Wired Access
5.2 Wired Access Connect PC to UF51 LAN port directly or through PoE injector. The following steps are based on Windows 10 operating system for your reference. A. Go to “Control Panel” → “Network and Internet” → “Network and Sharing Center”, then click “Ethernet”... -
Page 13: Network Connection
If you enter the username or password incorrectly more than 5 times, the login page will be locked for 10 minutes. E. After logging in the web GUI, you can view system information and perform configuration of the device. 6. Network Connection This section explains how to connect the device to network via WAN connection, Wi-Fi or cellular. - Page 14 B. Connect WAN port to other network devices like modem. C. Go to “Network” → “Interface” → “Link Failover” to enable WAN. D. Log in web GUI via WAN IP address and check the network connection.
-
Page 15: Configure The Wi-Fi Connection
6.2 Configure the Wi-Fi Connection A. Go to “Network” → “Interface” → “WLAN” and select “Client” mode. B. Click “Scan” to search for Wi-Fi access point. Select the available one and click “Join Network”. C. Type the key of Wi-Fi. D. -
Page 16: Configure The Cellular Connection
6.3 Configure the Cellular Connection A. Go to “Network” → “Interface” → “Cellular” → “Cellular Setting” page to enable cellular settings. B. Choose relevant network type and fill in SIM card information like APN or PIN code, then click “Save” and “Apply”. - Page 17 D. Go to “Status” → “Cellular” page to view the status of the cellular connection. If it shows “Connected”, it means the SIM has dialed up successfully. On the other hand, you can check the status of indicator. If it keeps light up statically, it means SIM has dialed up successfully. [END]...
