Renesas RTK0EMX270S00020BJ User Manual

Evaluation System for BLDC Motor
User's Manual

For your safety

Be sure to read this manual before using the Evaluation System for BLDC Motor（RTK0EMX270S00020BJ）
(hereafter, referred to as the Product)
・ Follow the instructions in this manual when using the Product.
・ Keep this manual near the Product so that you can refer to it whenever necessary.
・ Transfer or resale of the Product to third parties is prohibited without written approval.
・ The purchaser or importer of the Product shall ensure compliance with local regulations. In addition, the customer
is responsible for ensuring that the Product is handled correctly and safely in accordance with the laws of the
customer's country (region).
・ The manual for the Product and specification (hereafter, referred to as the Documents) are the tool which was
developed to evaluate function and performance of Renesas Electronics semiconductor device (hereafter, referred
to as the Renesas Electronics device) which is mounted on the Product, and not guarantee the same quality,
function and performance as our devices.
・ By purchasing the Product or downloading the Documents from Renesas Electronics website, the support services
provided from Renesas Electronics are not guaranteed.
・ All information contained in this manual represents information on products at the time of publication of this
manual. Please note that the product data, specification, sales offices, contents of website, address, etc., are
subject to change by Renesas Electronics Corporation without notice due to product improvements or other
reasons. Please confirm the latest information on Renesas Electronics website.
Meaning of Notations
In this manual, items related to the safe use of the Product are described as below.
■The degree of injury to persons or damage to property that could result if the designated instruction in this manual
is not followed is indicated as follows.
Note 1. Serious injury refers to conditions resulting in persistent after-effects and for which treatment would
necessitate hospitalization or regular hospital visits, due to injuries, such as loss of eyesight, burns (high- or low-
temperature), electric shock, bone fracture, poisoning.
Note 2. Injury refers to conditions for which treatment would necessitate hospitalization or regular hospital visits.
Note 3. Physical damage refers to damage affecting the wider surroundings, such as the user's house or property.
R12UZ0062EJ0100 Rev.1.00
2019.11.11
Indicates content that, if not followed, could result
in death or serious injury
Danger
which is highly urgent.
Indicates content that, if not followed, could result
Warning
in death or serious injury to the user.
Indicates content that, if not followed, could result
Caution
in injury*
to the user, and
(*1)
2
to persons or physical damage.*
User's Manual
3
Page 1 of 26
