Evaluation System for Stepping Motor with Resolver
User's Manual

Safety Precautions

Be sure to read this manual before using the Evaluation System for Stepping Motor with Resolver
(RTK0EMX270S01020BJ) (Called "this product" below).
・ Follow the instructions in this manual when using this product.
・ Keep this manual near this product so you can refer to it whenever necessary.
・ Transfer or sale of this product to third parties is prohibited without written approval.
・ The purchaser or importer of this product shall ensure compliance with local regulations. In addition, the
customer is responsible for ensuring that this product is handled correctly and safely, in accordance with the laws
of the customer's country (region).
・ The manuals and specifications related to this product (called "the documents, etc." below) are tools that were
developed for the function and performance evaluation of Renesas Electronics semiconductor devices (called
"Renesas Electronics devices" below) mounted on this product and do not guarantee the quality, function, and
performance equivalent to Renesas Electronics products.
・ By purchasing this product or downloading the documents, etc. from Renesas Electronics website, the support
services provided from Renesas Electronics are not guaranteed.
・ All information contained in this manual represents information on products at the time of publication of this
manual. Note that the product data, specifications, contact for inquiries, contents of website, address, etc., are
subject to change by Renesas Electronics Corporation without notice. Confirm the latest information on Renesas
Electronics website, etc.
Meaning of Notations
In this manual, items related to the safe use of the product are indicated as described below.
■The degree of injury to persons or damage to property that could result if the designated instruction in this manual
is not followed is indicated as follows.
Danger
Warning
Caution
*1 Serious injury refers to conditions resulting in persistent after-effects and for which treatment would
necessitate hospitalization or regular hospital visits, such as loss of eyesight, burns (high- or low-
temperature), electric shock, bone fracture, poisoning, or other injuries.
*2 Injury refers to conditions for which treatment would necessitate hospitalization or regular hospital visits.
*3 Physical damage refers to damage affecting the wider surroundings, such as the user's home or property.
R12UZ0065EJ0100 Rev.1.00
2019.11.29
Indicates a thing that, if not followed, could result in
death or serious injury
(*1)
highly imminent.
Indicates a thing that, if not followed, could result in
death or serious injury to the user.
Indicates a thing that, if not followed, could result in
injury
to persons or physical damage
(*2)
User's Manual
to the user, and which is
.
(*3)
R12UZ0065EJ0100
Rev.1.00
2019.11.29
Page 1 of 51
