Summary of Contents for Keysight Technologies E5818
- Page 1 Keysight E5818 LXI Class-B Trigger Box Rack Mount Installation Note...
- Page 3 One rack mount kit contains the hardware to mount a single E5818 onto full rack with BNC connections on the front.
- Page 4 Rubber Bumpers 2. Using Pozidriv screwdriver, attach Rack Ear-Half Rack (B) to the right side of the E5818 with three M4x10 Panhead Screws (C). 3. Using Pozidriv screwdriver, attach Rack Ear-Full Rack (A) to the E5818 with three M4x10 Panhead Screws (C).
- Page 5 Connect BNC cables (F). Plug AC Power Cord into AC Power port and the E5818. Rear View of the E5818 TTL2 EXT2 TTL1 EXT1 1PPS Power TTL 2 EXT 2 TTL 1 E XT 1 TTL OUT 1 1PPS TTL OUT 2...
- Page 6 This information is subject to change without notice. © Keysight Technologies 2007, 2008, 2015 Edition 3, January 2015 *E5818-90007* E5818-90007 www.keysight.com...
