PCNC 770 Stand Assembly
Product Identification: PCNC 770 Machine Stand (PN 31191)
Purpose: This document details the assembly of the PCNC 770 stand.
.
PCNC 770 Machine Stand
Qty
Stand
1
Stainless Steel Wear Guard
1
M6 Nut
2
M12 Flat Washer
8
M12 Spring Washer
4
Foot
4
Spacer
4
M12 x 50 mm Screw
4
M6 x 20 mm Screw
2
M6 x 10 mm Screw
12
Adjusting Rod
1
M6 Washer
12
M5 x 10 mm Screw
4
Left Chip Pan
1
Right Chip Pan
1
Key for Stand
2
Butyl Tape
1
M12 Threaded Stud
4
M12 Nut
4
NOTE: If any of these items are missing, contact Tormach
Customer Service at (608) 849-8381 for a replacement.
NOTE: Discard 12 M6 Flat Washers included with PCNC 770 Machine Stand. Butyl tape replaces these items.
Tormach Inc.
1071 Uniek Drive, Waunakee, WI 53597
Phone: 608.849.8381 / Fax: 209.885.4534
PN
—
—
—
—
—
35259
32092
—
—
—
—
—
—
—
—
—
34428
32648
—
Specifications subject to change without notice.
Page 1
©Tormach® 2011. All rights reserved.
TD10407_PCNC770_Stand_0216A
