Tormach PCNC 770 Quick Start Manual

Quick Start Guide
CNC SCaNNer
Getting started with CNC Scanner is easy

Download and install the software

1.
The freeware version of the software is available at http://www.tormach.com/Product_CNC_Scanner.html.
Download the software to your computer and double-click to begin installation.
Follow the instructions on screen.

Activate the software in Mach3

2.
2a. For Tormach PCNC install. Open Mach3. Choose ConfigConfig Plugins from the pulldown menu.
Ensure that the plugin topstools is enabled (displays green check mark next to the name).
If a red X appears instead, click on the box to enable and switch to a green check mark.
2b. For Generic Mach3 install. If the tops tools plugin does not appear in the Config plugins menu, then copy,
the file topstools.dll from folder C:/PCNC3/plugins/ to C:/Mach3/plugins/ and repeat Step 2A.
3.

Install the camera driver

Some webcams will need an additional driver to be installed for the camera to operate correctly.
Consult your camera's documentation if this is the case.
www.TORMACH.COM
(if applicable)
Enabling Your idEas
TD31455_CNC_Scanner.pdf • June 08, 2010
204 Moravian Valley Road, Suite N • Waunakee, WI 53597
Ph 608.849.8381 • Fx 209.885.4534 • © 2010 Tormach LLC
tormach tV
epiSode 001
Page 1 of 4
