Tormach PCNC 440 Installation Manual

Hide thumbs Also See for PCNC 440:
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

TECHNICAL DOCUMENT
INSTALLATION GUIDE: PCNC 440 STAND
Product Identification: PCNC 440 Stand (PN 35671)
Purpose: This document details assembly of the PCNC 440 stand.
Item# PCNC 440 Stand
1
Back Panel
2
Side Panel
3
Upper Support
4
Lower Support
5
Door Assembly
6
Mounting Block
7
Leg
8
Middle Shelf
9
Lower Shelf
10
Top Panel
11
10-32 x 1/2" Phillips Screw
12
10-32 x 3/8" Phillips Screw
13
M12 x 20 mm Socket Head Cap Screw
14
1/4-20 x 3/8" Phillips Screw
15
Door Lock
16
M12 Lock Washer
17
M12 Flat Washer
18
Leveling Foot
19
10-32 Nut
20
M12 Nut
NOTE: Some fasteners in this kit may include extras.
If any of these items are missing, contact Tormach
Customer Service at (608) 849-8381 for a replacement.
©Tormach® 2020. All rights reserved.
Specifications subject to change without notice.
TD10403_PCNC440_Stand_0120A
Qty.
1
2
2
2
1
4
4
1
1
1
8
60
12
4
2
12
4
4
12
4
Page 1
TORMACH.COM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCNC 440 and is the answer not in the manual?

Questions and answers

Related Manuals for Tormach PCNC 440

Summary of Contents for Tormach PCNC 440

  • Page 1 TECHNICAL DOCUMENT INSTALLATION GUIDE: PCNC 440 STAND Product Identification: PCNC 440 Stand (PN 35671) Purpose: This document details assembly of the PCNC 440 stand. Item# PCNC 440 Stand Qty. Back Panel Side Panel Upper Support Lower Support Door Assembly Mounting Block...
  • Page 2 TECHNICAL DOCUMENT Stand Parts ©Tormach® 2020. All rights reserved. Tormach, Inc. Specifications subject to change without notice. P: 608.849.8381 / F: 209.885.4534 TD10403_PCNC440_Stand_0120A tormach.com Page 2...
  • Page 3 2. Using six 10-32 x 3/8” Phillips Screws, attach Back Panel (see Figure 2). Using 10-32 panel as sh Figure 2 ©Tormach® 2020. All rights reserved. Tormach, Inc. Specifications subject to change without notice. P: 608.849.8381 / F: 209.885.4534 TD10403_PCNC440_Stand_0120A tormach.com...
  • Page 4 4. Using 12 10-32 x 3/8” Phillips Screws, attach Middle Shelf (see Figure 4). Using 10-32 the middle s Figure 4 ©Tormach® 2020. All rights reserved. Tormach, Inc. Specifications subject to change without notice. P: 608.849.8381 / F: 209.885.4534 TD10403_PCNC440_Stand_0120A tormach.com...
  • Page 5 Lower Shelf; these will be added later. Figure 5 6. Using 16 10-32 x 3/8” Phillips Screws, attach Top Panel to assembly (see Figure 6). Figure 6 ©Tormach® 2020. All rights reserved. Tormach, Inc. Specifications subject to change without notice. P: 608.849.8381 / F: 209.885.4534 TD10403_PCNC440_Stand_0120A tormach.com...
  • Page 6 Mounting Blocks (see Figure 7). 10. Repeat Steps 8-9 for second Upper Support. Figure 7 ©Tormach® 2020. All rights reserved. Tormach, Inc. Specifications subject to change without notice. P: 608.849.8381 / F: 209.885.4534 TD10403_PCNC440_Stand_0120A tormach.com...
  • Page 7 NOTE: Center hole in each Mounting Block is used for mounting mill to chip pan. For information on Stand Top assembly, refer to PCNC 440 Operator Manual. 12. Using one M12 x 20 mm Socket Head Cap Screw and one M12 Flat Washer, secure end...
  • Page 8 18. Return Stand to upright position; attach one Door Lock to each door (see Figure 11). 19. Adjust feet as needed to level stand. Figure 11 ©Tormach® 2020. All rights reserved. Tormach, Inc. Specifications subject to change without notice. P: 608.849.8381 / F: 209.885.4534 TD10403_PCNC440_Stand_0120A tormach.com...
