Tormach PCNC 1100 Deluxe Stand Technical Document

PCNC 1100 Deluxe Stand Installation
Product Identification: PCNC 1100 Deluxe Machine Stand with Coolant Kit (PN 30297)
Purpose: This document details the assembly and installation
of the PCNC 1100 mill stand. This document includes seven
sections including: (1) Receiving Stand; (2) Attaching Feet; (3)
Installing Manual Oiler (4) Attaching Chip Pans; (5) Attaching
Backsplash Guards; (6) Installing Coolant System; and (7)
Installing Table Guard Kit.
IMPORTANT! PCNC 1100 mills with serial numbers 001-2097
require a PCNC 1100 Stud Kit (PN 35468).
Required Tools:
• Multi-Purpose Grease
• Carpenter's Level
Deluxe Machine Stand with Coolant Kit
Stand
Left Chip Pan
Right Chip Pan
Coolant Tank
Stainless Steel Wear Guard
M6 x 10 mm Screw
M6 Nut
M12 Nut
M12 Threaded Stud
M12 Flat Washer
M12 Lock Washer
Spacer
Feet
M5 x 20 mm Screw
M6 x 12 mm Fixing Screw
Left Table Guard Plate
NOTE: If any of these items are missing, contact Tormach Customer Service for a replacement at (608) 849-8381.
