Cumberland BJ-C-32-SPI Owner's Manual

Super saver bunsen jet brooder with spi
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Models
BJ-C-32-SPI
BJ-C-42-SPI
If you smell gas:
1. Open windows.
2. Don't touch electrical switches.
3. Extinguish any open flames.
4. Immediately call your gas supplier.
Si vous sentez une odeur de gaz:
1. Ouvrez les fenetres.
2. Ne touchez pas aux interrupteurs electriques.
3. Eteignez toute flamme nue.
4. Contactez immediatement votre compangie
de gaz.
NOTE: Retain instructions for future reference
Super Saver Bunsen Jet Brooder with SPI
Owner's Manual
Rev 1/15
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
ll es interdit d'utiliser des liquides
inflammables ou degageant des vapeurs
inflammables, a proximite de tout
appareil fonctionnant au gaz.
Manual Part No. 4801-0060

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BJ-C-32-SPI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cumberland BJ-C-32-SPI

Summary of Contents for Cumberland BJ-C-32-SPI

  • Page 1 Owner's Manual Models BJ-C-32-SPI BJ-C-42-SPI If you smell gas: Do not store or use gasoline or other flammable 1. Open windows. vapors and liquids in the vicinity of this or any 2. Don't touch electrical switches. other appliance. 3. Extinguish any open flames.

  • Page 2: Table Of Contents

    Table of Contents 1. RATINGS AND SPECIFICATIONS ...................... 1 1.1. R ..............................1 ATINGS 1.2. G ......................1 RESSURE EQUIREMENTS 1.3. C ...................... 1 AUTION INIMUM LEARANCES 2. WARNINGS .............................. 2 3. LIMITED WARRANTY .......................... 3 4. PHYSICAL DESCRIPTION / DRAWING OF PRODUCT ..............3 5.

  • Page 3: Ratings And Specifications

    Ratings and Specifications 1.1. Ratings Minimum Ventilation Model No. Maximum Input (Air required to support combustion) 32,000 BTUH 320 CFM/brooder BJ-C-32-SPI (543.6 m /hr) (9.38 kW) 42,000 BTUH 420 CFM/brooder BJ-C-42-SPI (713.6 m /hr) (12.31 kW) 1.2. Gas Pressure Requirements Burner manifold gas pressure is to be 11 in.

  • Page 4: Warnings

    Warnings WARNING! Read and understand all the following precautions before installing or operating this Unit. Installation must comply with all local, state, and national codes. In the absence of local codes, in accordance with CAN1-B149.1 or 2 Installation Codes (Canada). Follow safety, maintenance, and test firing instructions packaged with brooder.

  • Page 5: Limited Warranty

    This warranty gives you specific legal rights and you may also have other rights which vary from area to area. Warrantor: Cumberland. 1004 E. Illinois St. Assumption, IL 62510 Physical Description / Drawing of Product The Super-Saver Bunsen Jet radiant brooder uses a reliable standing pilot ignition system to ignite the burner.

  • Page 6: Assembly

    All controls are located on the gas valve mounted on top of the brooder canopy. There are three controls you will use: the control knob, pilot purge button, and the thermostat knob, see illustration below. The control knob is located on the back side of the gas valve and has three positions: ON, OFF, and PILOT.

  • Page 7: Burner Unit Assembly

    3. Rotate the suspension rod until the swaged portion mates with the opening, push the suspension rod through the opening so that the opening is between the swage, then rotate the suspension rod so that it is positioned with the mounting pedestals pointing inwards toward the center of the support ring, as in Figure 3.

  • Page 8: Burner Unit Assembly

    5.4. Burner Unit Assembly 1. For burner unit assembly, see Figure 4, then follow these steps. 2. Position pilot bracket as shown in Fig. 4. Secure with two 8-32 X 1/2 screws and 8- 32 nuts (provided). Figure 4 8/32 Kep Lock Nuts Burner Assembly Pilot Bracket Thermocouple...
  • Page 9 Figure 5. Final Brooder Assembly 8-32 X 1/4 Screws Gas Valve Gas valve bracket and gas valve. Capillary Gas Valve Tubing Bracket Retaining Heat shield Clamps Cotter Pin 10-24 X 1/4 Screws 8-32 X 1/2 Nuts Canopy NOTE: Insert thermostat bulb Into holes of bracket Thermostat...

  • Page 10: Gas Tubing Assembly

    3. Place ceramic element on top of the support ring. 4. Insert the suspension rods through the three slotted openings in the canopy. Insert a cotter pin through the second and smaller opening in each of the suspension rods, then bend the longer leg of the cotter pin to the side. The pilot assembly should be aligned with the burner unit assembly, when facing the gas valve.

  • Page 11: Installation

    Installation Installation of your assembled brooder involves two steps: 1. Hanging the Unit 2. Gas Tube Hookup First we have an example drawing of how to hang the unit, then the next section covers gas hookup, including checking that the gas supplied to the unit is at the correct pressure. Remember to follow all safety precautions when hanging the unit, and hooking up the gas supply.

  • Page 12: Hanging Spi Galvanized Brooder With 34" Diameter Canopy

    6.1.2. Hanging SPI Galvanized Brooder with 34” Diameter Canopy The hanging kit for the 34” diameter galvanized steel brooder canopy includes an 11” chain and two 6” chains which must be attached as shown in Fig. 8 to ensure that the canopy will hang level. Join the three chains at the center of the canopy with a single S-hook.

  • Page 13: Gas Hookup

    All brooders must be connected to the gas supply with an AGA approved gas hose and fittings. An approved hose is available at your Cumberland dealer. 6.2.2 Checking Manifold Gas Pressure To be performed by a CERTIFIED GAS TECHNICIAN only! 1.

  • Page 14: Operating Instructions

    Operating instructions Placing Brooder in Service 1. Check that all installation steps in section 6 of this manual have been performed. Read and understand warning statements in section 2. 2. Open gas supply valve. 3. Turn control knob on gas valve to the PILOT position. 4.

  • Page 15: Troubleshooting Guide

    Troubleshooting Guide Symptom Possible Cause Solution Pilot orifice may be restricted. Clean the orifice. Thermocouple is not sensing Replace thermocouple. the pilot flame. Pilot will not remain lit. Check thermocouple position. If Thermocouple misaligned problem persists, replace thermocouple. Thermostat may not be set Set thermostat to desired house properly.
