Summary of Contents for SPAN PressureGuard EASY AIR Series
- Page 1 OWNER’S MANUAL ® PressureGuard EASY AIR ® Series ® ® ® PressureGuard PressureGuard PressureGuard EASY AIR EASY AIR EASY AIR ® ® ® Span-America Medical Systems, Inc. 800-888-6752 www.spanamerica.com P09564 R4 CO# 2340...
- Page 2 P09564 R4 CO# 2340...
-
Page 3: Table Of Contents
TABLE OF CONTENTS DOCUMENT SYMBOLS ................................. 5 INTRODUCTION ....................................6 INTENDED USE INDICATIONS FOR USE GENERAL DESCRIPTION MODES OF OPERATION PRODUCT DESCRIPTION................................8 THE SCIENCE BEHIND THE EASY AIR LOW AIR LOSS DESIGN ................. 9 MATTRESS and CONTROL UNIT SETUP DIRECTIONS ....................8 ELECTROMAGNETIC OR OTHER INTERFERENCE ....................... - Page 4 P09564 R4 CO# 2340...
-
Page 5: Document Symbols
DOCUMENT SYMBOLS This manual contains different typefaces and symbols to make the content easier to read and understand: • Standard text – used for regular information. • Boldface text – stresses a word or phrase. • NOTE: - sets apart special information or important instruction clarification. •... -
Page 6: Introduction
2. Never operate the product’s powered control unit if it has a damaged cord or plug, is not working properly, has been dropped or damaged, or has been exposed to water. Contact Span-America Medical Systems, Inc. for examination and repair. - Page 7 Warning: This product contains/may contain chemicals known to the state of California to cause cancer and/or birth defects or other reproductive harm. We believe the PressureGuard Easy Air sets a new standard for low air loss mattress systems. Thank you for choosing Span-America! P09564 R4 CO# 2340...
-
Page 8: Product Description
PRODUCT DESCRIPTION Span-America’s patented use of non-collapsible “air diffusion matrix” fabric in both the inner air delivery cover and the outer removable coverlet maintains an air pathway underneath the user, thus transporting moisture vapor away from the user’s skin. Both the inner air-delivery cover and the outer removable coverlet are bacteriostatic, flame resistant and fluid proof. - Page 9 ILLUSTRATION DESCRIPTIONS 1. Outer Removable The purple-colored coverlet is fluid proof, cleanable and flame resistant. It can Coverlet: be replaced if damaged or worn. The outer coverlet is highly vapor permeable (4500 grams/meter /24 hours) and fluid-proof. Both of its fabrics (smooth top fabric and the crush-proof air diffusion matrix fabric) are bacteriostatic.
-
Page 10: The Science Behind The Easy Air Low Air Loss Design
THE SCIENCE BEHIND EASY AIR LOW AIR LOSS DESIGN Easy Air’s exclusive “Air Diffusion Matrix” design maximizes removal of excess moisture (i.e., perspiration) from the user’s skin. Moisture passes in vapor form down through the cover, where a continuous air current takes it away before it can re-form as liquid. -
Page 11: Mattress And Control Unit Setup Directions
MATTRESS AND CONTROL UNIT SET-UP DIRECTIONS 1. Place the mattress on a standard hospital bed frame or on a box spring, with the purple coverlet facing up, and the connector access at the foot-end of the bed, to the patient's right. Note that the connector access is on the inner gray top surface air delivery cover, which should also be facing up, under the purple coverlet. -
Page 12: Electromagnetic Or Other Interference
which are interchangeable. Verify secure connection with two clicks. On the LR model (four fittings mounted into one connection plate.) and XL (six fittings mounted into one connection plate) models, click connectors into place in appropriate fittings on side of control unit. Verify secure connection with “click”... -
Page 13: Easy Air Xl
CONTROL UNIT SETTINGS 1. Turn unit ON at the switch provided on the lower left-hand side of the air-control unit. 2. Select the desired THERAPY MODE. - For Standard and XL models, select FLOAT or ALTERNATING as desired. - For LR model, select FLOAT or ALTERNATING or ROTATION. 3. - Page 14 LOW PRESSURE indicator will illuminate. LOW PRESSURE indicator will remain until being replaced by the green NORMAL PRESSURE indicator, signaling that the mattress is ready for patient use. If NORMAL PRESSURE indicator does not illuminate within 20 minutes of power up, contact Span- America for assistance.
- Page 15 LOW PRESSURE indicator will illuminate. LOW PRESSURE indicator will remain until being replaced by the green NORMAL PRESSURE indicator, indicating that the mattress is ready for patient use. If NORMAL PRESSURE indicator does not illuminate within 20 minutes of power up, contact Span- America for assistance.
- Page 16 LOW PRESSURE indicator will illuminate. LOW PRESSURE indicator will remain until being replaced by the green NORMAL PRESSURE indicator, indicating that the mattress is ready for patient use. If NORMAL PRESSURE indicator does not illuminate within 20 minutes of power up, contact Span- America for assistance.
-
Page 17: General Directions For Use
BED RAILS: Due to concerns over the possibility of patient entrapment, Span-America recognizes that the use of rails of any length is a matter currently addressed by federal and state laws/guidelines, and by individual facility protocol. -
Page 18: Storage And Transportation
• Mains Supply Voltage Fluctuation up to 10 +/-% of the nominal voltage • Overvoltage Category II • Pollution Degree 2 Store the mattresses in a clean, dry place. Once the mattress is removed from the box, store flat on a clean STORAGE AND TRANSPORTATION surface. - Page 19 If required, the air control unit can be cleaned and disinfected. Turn unit off and unplug from wall before cleaning. [Note: The mattress will maintain air with the unit unplugged. The unit will resume previous setting when powered back up]. Wipe down with using damp sponge or cloth that has been thoroughly wrung out to remove excess liquid.
-
Page 20: Preventive Maintenance
3. Wash filter using mild soap and water. Pat dry with towel. NOTE: If filter is damaged or cannot be easily cleaned, it should be discarded and replaced with a new filter, Span-America part number P02549. P09564 R4 CO# 2340... -
Page 21: Mattress
7. Report any unusual sounds, burning odors, or anything unusual to maintenance personnel. Discontinue use of the power cord immediately and contact Span-America Medical Systems, Inc. for replacement. MATTRESS P09564 R4 CO# 2340... - Page 22 Inspect the covers and zipper area for signs of damage, puncture, or wear that could result in fluid pass-through. If the cover is stained, soiled, or torn, inspect the internal components for signs of contamination. If contamination is evident, quarantine the mattress and remove from service following infection control procedures.
-
Page 23: Specifications
XL version: 1000 lbs (a) Use of main power cords other than that supplied with product by Span-America (P02337) may affect EMC compliance with UL regulations. Power cords other than recommended by manufacturer or at lengths other than supplied length may increase Emissions or Decrease Immunity. -
Page 24: Ordering Information
ORDERING INFORMATION Systems include mattress with removable coverlet, inner cover and control unit. Version: PressureGuard Easy Air (Standard) System low air loss with alternating pressure. Control Unit 8000eystem Replacement Removable System # Mattress Size Mattress Only Inner Cover Inflation Coverlet Only System L7535 -29 75"L x 35"W x 7"H... - Page 25 Items not shown below: Filter replacement P02549 (package of 12 filters) Fuse replacement P09531 1 Amp/ 250 V slo blo Parts List P02376 Small, Female, (8000 model only, requires 2 each) P09533 Large Female, (all models requires 1 each) ...
-
Page 26: Trouble Shooting Guide
Adjust each gatched. as necessary to meet patient needs while maximizing turn angle. Call Span-America for assistance with Patient exceeds weight limit. product selection. Control Unit is not turned on. Turn control unit on. - Page 27 Turn on airflow. Call for service if Blower not operating. Airflow not on. problem not resolved. Turn Air Flow off, call Span-America for Cover billowing Weld failure in top of mattress cover. replacement cover. Technical Service: (800) 888-6752...
- Page 28 P09564 R4 CO# 2340...
- Page 29 PressureGuard Easy Air Preventive Maintenance and Repair Log Date Air Filter Power Cord Mattress Repair Manufacturer: Span-America Serial #: C=Cleaned OK=Okay Date Purchased: R=Repaired/Replaced P09564 R4 CO# 2340...
- Page 30 P09564 R4 CO# 2340...
- Page 31 P09564 R4 CO# 2340...
- Page 32 THIS PRODUCT IS PROTECTED BY ONE OR MORE OF THE FOLLOWING U.S. PATENTS: 6,782,574 6,223,369 6,848,138 7,296,315 SPAN-AMERICA MEDICAL SYSTEMS, INC. Greenville, SC 29615 800-888-6752 P09564 R4 CO# 2340...
