Realtree RTLS-502 Manual page 9

Assembly Instructions Page 4
7
I
50
7
Attach Back Shooting Rail
8b
53
Q
F
Attach combined Shooting Rail
to the Armrest
8b
2-M6x53mm bolt w/3 washers
on each side.
Distributed by Primal Vantage Company Inc., 2407 W. Euclid Ave., Littleton, CO 80120
CUSTOMER SERVICE DEPARTMENT 1-866-972-6168
I
50
using 2-M6X50 bolts .
53
J
F
using
53
8a
50
Q
Insert Shooting Rail Sides
8a
and secure with 1-M6x25mm bolt on each side
9
F
J
9
Q Attach Rail Covers
Cushion
MODEL: RTLS-502
15 Ft. Two-man Ladderstand
