In the box
Thermostat
Drywall screws (3) Drywall anchors (3)

Recommended tools

Phillips screwdriver Power drill (3⁄16" drill bit)
2
Back plate Trim plate
AA batteries (4)
Pencil Needle-nose pliers

Thermostat overview

Buttons
UP: Adjust target temperature up.
MODE: Change thermostat between
HEAT, COOL, AUTO, EMER
and OFF modes.
DOWN: Adjust target temperature.
Also include and exclude from
the network.
Modes
HEAT: Will activate the heating system.
COOL: Will activate the air conditioner.
AUTO: Will select either the HEAT
or COOL mode automatically.
EMER: For use with heat pumps only.
Will bypass the heat pump and
enable auxiliary/emergency heat.
OFF: The system will not heat or cool.
Display
HEAT: Illuminated in HEAT, EMER
or AUTO mode.
COOL: Illuminated in COOL
or AUTO mode.
RADIO: Illuminated during the
wireless configuration.
❶
Display
❺
❷
Heat
❻
❸
Cool ❶
❼
❹
Radio
❺
❹
Up
❸
❻
❷
Mode
❼
Down
