Thermostat overview

Buttons
MENU: Access options to change the
mode, fan, settings, and other features.
UP: Adjust setpoint up or navigate
the MENU.
DOWN: Adjust setpoint down or
navigate the MENU.
SELECT: Select options in the MENU.
Modes
HEAT: Will activate the heating system.
COOL: Will activate the air conditioner.
AUTO: Will select either the HEAT or COOL
mode automatically.
EMER: For use with heat pumps only. Will bypass the
heat pump and enable auxiliary/emergency heat.
OFF: The system will not heat or cool.
Display
HEATING: Illuminated in HEAT, EMER or AUTO
mode when the thermostat is calling for heat.
COOLING: Illuminated in COOL or AUTO mode
when the thermostat is calling for cool.
Illuminated when the thermostat is using one
or more Alarm.com Temperature Sensors.
❶ Display
❷ Up
❸ Down
❹ Menu
❻
❹
❺
❺ Select
❻ Room Temperature
❼ Setpoint
❷
❶
❸
❼
