The N56kWi flue diverter (black UV resistant PP) is a flue accessory kit

that allows you to move the flue terminal position up and away from the air

intake by up to 1.5 m. It is designed for when a traditional horizontal terminal

cannot be installed due the flue being a nuisance or due to flue restrictions.

It works in conjunction with the horizontal flue terminal (part FFP100HKIT).

Flue diverter kit (FFP100DIV) includes:

•

elbows

•

connecting flue pipe 1000 mm

•

flue extension

•

wall brackets

•

fasteners

INFINITY N56kWi flue diverter kit

Installation guide

x 2

x 1

x 3 (off-centre fixing)

not supplied

1000 mm

695 mm

196 mm

Table of Contents

Need help?

Do you have a question about the INFINITY N56kWi and is the answer not in the manual?

Page 1 Flue diverter kit (FFP100DIV) includes: • elbows • connecting flue pipe 1000 mm • flue extension • wall brackets x 3 (off-centre fixing) • fasteners not supplied 1000 mm 695 mm 196 mm INFINITY N56kWi flue diverter kit Installation guide...
Page 2 The N56kWi flue diverter, code FFP100DIV, is manufactured from polypropylene. It has been tested and can ONLY BE used with the Rinnai INFINITY N56kWi water heater. The flue diverter is tested and approved for use with the a maximum flue gas temperature of 120 °C.
Page 3 3. Deburr sharp edges as this could damage the seals resulting in a system that is no longer air- tight. Internal chamfer for ONLY cut the external connection only, DO chamfered end NOT CUT Rinnai INFINITY N56kWi flue diverter installation guide12745-A 01-20 | 3...
Page 4 Rinnai.co.nz Rinnai New Zealand Limited 105 Pavilion Drive Mangere, Auckland 2022 PO. Box 53177 Auckland Airport Auckland 2150 Tel: 0800 746 624 http://www.youtube.com/rinnainz INFINITY N56kWi flue diverter installation 12745-A http://facebook.com.rinnainz...
