Summary of Contents for Rinnai RH-TL65C-SSVR
- Page 1 RH-TL65C-SSVR RH-TL75C-SSVR RH-TL95C-SSVR Cooker Hood Instructions for use installation and connection...
-
Page 2: Table Of Contents
Maintenance and care --------------------------------------------------------------------------------------------------------------------- 7 Troubleshoot --------------------------------------------------------------------------------------------------------------------------------- 8 IMPORTANT To register your product warranty, please paste the serial numbers stickers enclosed with the packaging on your warranty card. Please contact your local Rinnai Customer Care Centre should you require further assistance. Version: 2019.0... -
Page 3: Safety Warnings
SAFETY WARNINGS Please read this user manual thoroughly before attempting to use this appliance for the first time. This manual contains important information on safe installation, use and care of the appliance. Keep these instructions for reference and pass them on to future user. Unpacking For the user Do not use the appliance if there are obvious signs... - Page 4 Do not flambé or grill with an open flame directly under the extractor hood. Flames could be drawn up into the hood by the suction and the grease filters may catch fire. Monitor cooking continuously as overheated oil increases the risk of self-ignition. Do not operate the extractor hood without a grease filter.
-
Page 5: Appliance Specifications
SPECIFICATIONS Model RH-TL65C-SSVR RH-TL75C-SSVR RH-TL95C-SSVR Voltage 220V-240V~ / 50-60Hz 130W Power of Motor Power of Lamp 1 x 2W 2 x 2W 2 x 2W Cable Length 1.5m (W x D x H) - mm Appliance Dimension 599 x 298 x 217... -
Page 6: Installation
INSTALLATION This appliance can be installed in ducted or recirculation mode. Ducted mode (Fig. 4) In ducted mode, the extractor hood fan extracts the cooking vapours and passes them through the grease filter. The air then flows to the outside. The grease filter absorbs the solid particles in the cooking vapors. -
Page 7: Operation
OPERATION To achieve better air extraction, we recommend you to switch on the blower a few minutes before starting to cook. Leave it on for approximately 15 minutes after cooking or till all cooking smell is completely removed. Speed settings (Fig. 8) : Switches the fan on at high speed. -
Page 8: Maintenance And Care
MAINTENANCE AND CARE Disconnect the power supply cord before carrying out any cleaning or maintenance activities. It is important to clean and/or replace the filters at appropriate intervals as grease deposits build-up increases the risk of fire. Do not operate the extractor hood without grease filter. -
Page 9: Troubleshoot
Please contact Rinnai contact with fan blade Customer Care Service Whirring sound Lights are not working If problem persists after the above checks, please contact Rinnai Customer Care Centre for assistance. RANGE HOOD MODEL : RH-TL65C-SSVR Please quote the model number of your appliance as shown on the rating plate... - Page 10 2805 ประเทศไทย 內 บริ ษ ั ท ริ น ไน (ประเทศไทย) จํ า กั ด 電話 เลขที / ซอยกิ งแก้ ว ถนนกิ งแก้ ว ตํ า บลราชาเทวะ 傳真 อํ า เภอบางพลี จั ง หวั ด สมุ ท รปราการ ประเทศไทย ျမန္ မ ာ အမွ...
