Table of Contents
Advertisement
Warning.......................................................
Parts Name...................................................
Installation....................................................
Model:RH-9021A
Installation Instruction.....................................
Caution.........................................................
Operation Instruction.......................................
Maintenance & Cleaning...................................
Trouble Shooting.............................................
Warranty & Wiring Diagram............................
COOKER HOOD
INSTRUCTION MANUAL
NAME
Products and accessory ..............1
Instruction...............................3
Caution..................................4
Operating Instruction................5
Maintenance ＆ Cleaning...........6
Trouble Shooting.....................7
Wiring Diagram.......................8
Specification...........................9
PAGE
Advertisement
Table of Contents
Related Manuals for Rinnai RH-9021A
Summary of Contents for Rinnai RH-9021A
-
Page 1: Table Of Contents
COOKER HOOD INSTRUCTION MANUAL Warning………………………………………………. Parts Name…………………………………………… PAGE NAME Installation……………………………………………. Model:RH-9021A Products and accessory …..………1 Installation Instruction………………………………. Caution………………………………………………... Dimensions………………………...2 Operation Instruction………………………………… Instruction…………………….…...3 Maintenance & Cleaning…………………………….. Caution…………………………….4 Trouble Shooting……………………………………… Warranty & Wiring Diagram………………………. Operating Instruction……….…...5 Maintenance ＆ Cleaning…..6 Trouble Shooting…………………7 Wiring Diagram………………..…8... -
Page 2: Products And Accessory
PART NAME Capacitor RH-9021A Electric Box Cover Electric Box Control Board Power cable Fan Blade (Right) Tube top cover Fan Blade (Left) Motor Ventilator Body Ventilator seal Oil Plate Main Tube Unit Glass Body Oil Cup LED Light Switch cover... -
Page 3: Dimensions
Dimensions MODEL RH-9021A 210mm 896mm 510mm Hook Location A 153(6") 60mm... -
Page 4: Instruction
Installation 1. Main Set Installation: The minimum distance between the cooker and the appliance is 75-90CM, and drill holes on the wall. Screw the main set by using screw nut together. Adjust the main set till horizontal line. 75-90CM 650mm 保持水平... -
Page 5: Caution
Caution Surrounding Environment: The cooker hood should install near outdoor window. Let the exhaust air from the tube blow out easily thru the window. Alternatively, make a hole on the wall, and let the exhaust air from the aluminium tube blow out. Do not squash the aluminium tube into the hole. -
Page 6: Operating Instruction
Operating Instruction RH-9021A Light Control Turbo Button Middle Speed Low Speed Power. Control Button Control Button Control Button Button Power control button 1. Push this button to turn on the power and power indicator light will be on . 2. Push again to turn off power、power indicator light and all functions. -
Page 7: Maintenance ＆ Cleaning
Maintenance ＆ Cleaning …. 1. There is a fire risk if cleaning is not carried out in accordance with the instructions. 2. Be careful of the flame when cooking alcoholic food. It might cause to burn the cooker hood. 3. Make sure the ventilation is good when using glass hob and cooker hood together. -
Page 8: Trouble Shooting
Trouble Shooting 1. Motor Malfunction: Check the electrical wiring. Check the power plug, On / Off switch, or fuse. Check the impeller. If can move by hand when power is on, means the condenser capacitor needed to be changed. ... -
Page 9: Wiring Diagram
Wiring Diagram RH-9021A MOTOR BLACK BLACK ( BROWN) FUSE POWER WHITE WHITE ( BLUE) ELECTRIC BOARD WHITE GRAY BLACK BLUE WHITE LAMP CONDENSER YELLOW Control Board LAMP... -
Page 10: Specification
Specification MODEL RH-9021A DATA MATERIAL SUS430+Glass W896xD510xH520~960mm SIZE (＊Height: From button of main unit) OUTLET DIA 153mm FAN SIZE 14CMx2 MOTOR, S INSULATION VOLTTAGE/FREQUENCY 240V/50Hz 1.5A LIGHT SPEED Ⅰ Ⅱ Ⅲ MOTOR SPEED 1200rpm 1800rpm 2400rpm CONSUMPTION POWER 180W 220W...
