Titon Vent Trex User Manual

Vent-Trex is a unique combined overhead extract fan and
trickle ventilator for kitchens and bathrooms that fits within
the aperture on top of the window frame.
Vent-Trex is ideal for refurbishment situations where wall
penetration is undesirable, as it does not damage the fabric
of the building or where external aesthetics need to be
preserved.
It provides a trickle ventilation performance Equivalent Area
(EA) of 2500mm² minimum and extract ventilation rates to
suit either kitchens or bathrooms.
Motor protection: IP24 Rating CE marked according to LVD and
EMC directives.
Equivalent Area figure of 2500mm² achieved with a 300mm long fan
Pull Cord Length - 1m Long
Finish - Standard finish is white RAL 9010, other internal and external painted finishes are available, dependent
upon volume.
Handing - Units can be either left or right hand, viewed from the inside. Right denotes the side the snib, pull
cord and indicator light are at. (see photo above).
End Entry
Generally used where cables are being buried into
the wall.
Remote PSU photo
1
894 The Crescent, Colchester Business Park, Colchester, CO4 9YQ

Vent Trex - General Information

Front Entry
Generally used where cables are running inside
surface mounted trunking.
Remote PSU – fits into 40mm double patress box (not
supplied)
Sales and Technical Support - +44 (0) 1206 713800
- User Guide
Right hand option shown
(viewed from the inside)
ventsales@titon.co.uk www.titon.com
BM1361 Iss 01
