19.11.2021, 11:52
Base Block is a compact and multifunctional GPS/GLONASS vehicle tracking device that
is suitable for a wide range of tasks in the field of transport monitoring and fleet
management. The device not only allows to track the vehicle's location in real time but
also to apply a wide range of features due to the option of connecting up to 16 additional
sensors and connecting to the CAN-bus of the vehicle.
Base Block modifications:
Galileosky Base Block
Galileosky Base Block Lite
Galileosky Base Block Optimum
Galileosky Base Block Wi-Fi
Galileosky Base Block Wi-Fi Hub
Galileosky Base Block Iridium
Package
The standard package includes Galileosky tracker,
SIM-holder
a connector with contacts
fuse with holder
passport
a certificate of equipping a vehicle with GLONASS/GPS devices.
You will also need USB-cable and Power supply unit 9-39V (15 W).
Tech specs
Parameter
Analog-discrete
base.galileosky.com/articles/#!en-documentation/base-block-user-manual
Base
Base
Block Lite
Block
Optimum
4 pcs;
Base Block
Base
Base
Block Wi-
Block Wi-
Fi
Fi Hub
Base Block
Iridium
1/28
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for GalileoSky Base Block
Summary of Contents for GalileoSky Base Block
- Page 1 19.11.2021, 11:52 Base Block Base Block is a compact and multifunctional GPS/GLONASS vehicle tracking device that is suitable for a wide range of tasks in the field of transport monitoring and fleet management. The device not only allows to track the vehicle’s location in real time but also to apply a wide range of features due to the option of connecting up to 16 additional sensors and connecting to the CAN-bus of the vehicle.
- Page 2 19.11.2021, 11:52 Base Block and pulse voltage range -0-33V; frequency inputs maximum measured frequency-4 kHz Transistor 2 pcs.; maximum voltage 30V; maximum current 80mA. outputs (output 0/1) Battery type Li-Ion battery; 600mAh Average power 0,48 W 0,54 W 0,6 W...
- Page 3 8kHz Frequency of autoinformer discretization Speaker output analog, 250mW type By means of creating Easy Logic algorithms, stored in the tracker’s Enhancement memory and executed with no interference with the firmware Protocol of data 1. Galileosky: variable length-tag. base.galileosky.com/articles/#!en-documentation/base-block-user-manual 3/28...
- Page 4 19.11.2021, 11:52 Base Block transmission 2. EGTS (GOST R 54619-2011, Order № 285 of the RF Ministry of Transportation) Enclosure IP54 protection GLONASS/GPS external, Fakra aerial GSM aerial external, Fakra Wi-Fi aerial external external Iridium aerial external Operating -40…+85 °C...
-
Page 5: Safe Operating Rules
19.11.2021, 11:52 Base Block Average service 10 years life Warranty (from 5 years 2 years date of purchase) Internal Li-Ion 500 charge/discharge cycles, three years maximum battery life Safe Operating Rules Before using the tracking device, study the instructions of GSM/3G/GPRS devices safe operating. - Page 6 19.11.2021, 11:52 Base Block Positive supply voltage Negative supply voltage Zero analog-discrete input 1st analog-discrete input 2nd analog-discrete input 3rd analog-discrete input RS485A A signal of RS485 channel RS485B B signal of RS485 channel RXD0 RXD signal of zero RS232 port (only for Optimum/Iridium/Wi-Fi/Hub/3G m...
-
Page 7: Connecting Glonass Aerial
19.11.2021, 11:52 Base Block Connecting GLONASS aerial The top of the aerial must face the sky. To get the best view of the sky, we recommend installing the aerial on the roof or on the windshield, or under the dashboard of the vehicle. -
Page 8: Connecting Gsm/3G-Aerial
19.11.2021, 11:52 Base Block Blinking of the green LED 1 time means successful reception of a signal from the satellites. Connecting GSM/3G-aerial Position the GSM/3G antenna in such a way that the GSM/3G network signal is not strongly weakened by the metal housing of the vehicle. -
Page 9: Led Indicators
19.11.2021, 11:52 Base Block LED indicators Red LED is on when the power unit is connected to the tracking device. Yellow LED is on when the microcontroller is running (blinks with the frequency of 1 Hz). It is also used to indicate the bootloader mode. -
Page 10: Discrete-Analog Inputs (Dai)
19.11.2021, 11:52 Base Block Discrete-analog inputs (DAI) Tracking device has 4 discrete-analog inputs. Feature Value Maximum measured voltage 33 V Analog inputs resolution 1 mV Maximum transmitted signal 4 kHz frequency DAI have the following settings: Parameter Explanation Filter type (input... -
Page 11: Pulse Count
19.11.2021, 11:52 Base Block Ranges for To process discrete signals, response/ response/nonresponse range should be nonresponse areas set where signals are equal to one and (logical 1 and 0) zero. Discrete inputs states should be seen in the Status of Inputs field, but not in the Input voltage field. -
Page 12: Frequency Count
19.11.2021, 11:52 Base Block The mean value is calculated continuously and is put into the corresponding field IN0. At the same time, it is continuously checked whether the calculated value belongs to the given range. If it is in the range 8-33V, the corresponding bit will find itself in the Status of Inputs field and a point will be recorded. - Page 13 19.11.2021, 11:52 Base Block Determination of Strike and Incline All devices can determine the device`s strike and incline. To determine strike: Install the tracking device so as one of the accelerometer axis looks vertically, it will exclude false detections on road bumps;...
-
Page 14: Monitoring Data Transmission
The tracker accounts transmitted data separately for each server, thus, both will receive full archive with the track. Data can be transmitted according to the Galileosky or EGTS protocol. Algorithm (http://tomstdenis.tripod.com/xtea.pdf) is used for coding. The data are archived in the internal flash-memory by default. -
Page 15: Operation With Sim-Microchip
19.11.2021, 11:52 Base Block Options for storing and sending archive data: first the newest, then the oldest, in the chronological order. If the archive is on a microSD card, the data is always sent in chronological order. Operation with SIM-microchip Applicable for modifications Optimum/Iridium/WI-FI/Hub only. -
Page 16: Led Operation During Reflashing
19.11.2021, 11:52 Base Block OUT0…OUT3 outputs relay connection circuit LED operation during reflashing Depending on the GSM/3G-modem and microcontroller units activation stages, the tracker will go through the following stages: Yellow LED GSM/3G-modem activation stage blinking, times Procedure of GSM/3G-unit activation was successful. - Page 17 19.11.2021, 11:52 Base Block Bit number is entered in mainpackbit and headpackbit commands for selecting parameters, transmitted to the server. № Description Hardware version Firmware version IMEI Device’s identifier Number of an archive record Greenwich date and time Coordinates in degrees, number of satellites, indication of...
- Page 18 19.11.2021, 11:52 Base Block 2. number of impulses; 3. frequency,Hz. Input voltage 1, mV Depending on settings: 1. voltage, mV; 2. number of impulses; 3. frequency,Hz. Input voltage 2, mV Depending on settings: 1. voltage, mV; 2. number of impulses;...
- Page 19 19.11.2021, 11:52 Base Block Thermometer 4 identifier and measured temperature, C Thermometer 5 identifier and measured temperature, C Thermometer 6 identifier and measured temperature, C Thermometer 7 identifier and measured temperature, C iButton first key identification number CAN-bus (CAN_A0) and CAN-LOG data. Fuel used by a vehicle from the date of manufacturing, l.
- Page 20 19.11.2021, 11:52 Base Block CAN8BITR7 or lower byte of prefix P CAN-LOG CAN8BITR8 or higher byte of prefix WA CAN-LOG CAN8BITR9 or 4 byte of prefix WA CAN-LOG CAN8BITR10 or 3 byte of prefix WA CAN-LOG CAN8BITR11 or 2 byte of prefix WA CAN-LOG...
- Page 21 19.11.2021, 11:52 Base Block 1. CAN16BITR2 2. the 3 vehicle`s axle load, kg 3. failure code OBD ΙΙ Depending on settings: 1. CAN16BITR3 2. the 4 vehicle`s axle load, kg 3. failure code OBD ΙΙ Depending on settings: 1. CAN16BITR4 2.
- Page 22 19.11.2021, 11:52 Base Block 2. CAN-LOG, user`s prefix Depending on settings: 1. CAN32BITR3 2. CAN-LOG, user`s prefix Depending on settings: 1. CAN32BITR4 2. CAN-LOG, user`s prefix Input voltage 4. Depending on settings: 1. voltage, mV; 2. number of impulses; 3. frequency,Hz.
- Page 23 19.11.2021, 11:52 Base Block 1. voltage, mV; 2. number of impulses; 3. frequency,Hz. Input voltage 7. Depending on settings: 1. voltage, mV; 2. number of impulses; 3. frequency,Hz. Zero DS1923 sensor Identifier, measured temperature C and humidity %. The 1 DS1923 sensor Identifier, measured temperature C and humidity %.
- Page 24 19.11.2021, 11:52 Base Block RS485. A value from fuel level sensor with address 1. RS485. A value from fuel level sensor with address 2. RS485. Fuel level sensor with address 3. Relative fuel level and temperature. RS485. Fuel level sensor with addresses 4-14, with numbers 81- 91.
- Page 25 19.11.2021, 11:52 Base Block Tags CAN32BITR6 – CAN32BITR13 similar to CAN32BITR5 with numbers 162-169 CAN32BITR14 REP-500 electricity meter readings Refrigeration unit data EcoDrive and driving style determination PressurePro tires pressure monitoring system, 34 sensors User 0 data Tags from users data with numbers 178-183...
-
Page 26: Warranty
RSA “Galileosky”, LLC hereby guarantees the realization of consumers’ rights provided by the local laws throughout Russia and the CIS. RSA “Galileosky”, LLC guarantees the operability of the tracking device subject to compliance with the instructions set out in the above user`s manual. - Page 27 19.11.2021, 11:52 Base Block Traces of oxidation of outer and inner parts or exposure of the device body to moisture; Theft or criminal damage of the external aerial or cable; Damages caused by foreign objects, substances, liquids, insects coming into body;...
- Page 28 How to connect sensors and external devices? How to install a device in a vehicle? Ноw to find any CAN data? How to create Easy Logic algorithms? What commands can you use to configure the device? How to apply Galileosky protocol on a server? base.galileosky.com/articles/#!en-documentation/base-block-user-manual 28/28...
