- Page 1 Switching on Galileosky 5.0, 5.1 Devices for the First Time User Manual www.galileosky.com...
-
Page 2: Table Of Contents
Switching on Galileosky 5.0, 5.1 Devices for the First Time version 6 dated from June 19, 2018 Contents Necessary Tools, Devices, Materials ............3 Preparing of Galileosky Device to Switch-on ..........4 Preparing of a tracking device socket unit ..........4 SIM-cards inserting ................ -
Page 3: Necessary Tools, Devices, Materials
6 dated from June 19, 2018 Necessary Tools, Devices, Materials Before connecting the Galileosky Tracking device (hereinafter – tracking device, device) you should have: Power supply: 12V and more, not less than 1А SIM-card with «GPRS» и «SMS» activated Windows-based computer with installed Galileosky devices configuration software –... -
Page 4: Preparing Of Galileosky Device To Switch-On
Switching on Galileosky 5.0, 5.1 Devices for the First Time version 6 dated from June 19, 2018 Preparing of Galileosky Device to Switch-on Preparing of a tracking device socket unit Together with a device you get a counterpart of socket and several crimped conductors. -
Page 5: Sim-Cards Inserting
Switching on Galileosky 5.0, 5.1 Devices for the First Time version 6 dated from June 19, 2018 Turn the contacts the locking mechanisms up and along the sides and insert them into the socket until clicking position (Pic. 3). Pic. 3... -
Page 6: Preparing Antennas
Switching on Galileosky 5.0, 5.1 Devices for the First Time version 6 dated from June 19, 2018 Pic. 5 Inserting the SIM-card Carefully without applying excessive force insert the SIM-holder with the card into the tracking device until locking focusing on the key drawn on the tracking device body (Pic. - Page 7 Switching on Galileosky 5.0, 5.1 Devices for the First Time version 6 dated from June 19, 2018 antenna plug. The GLONASS/GPS antenna plug of the tracking device provides the necessary voltage for operation. Pic. 8 GLONASS/GPS- antennas Connect the GSM-antenna and the GLONASS/GPS-antenna to correspondent plugs as it is shown in Picture 9.
-
Page 8: Preparing Of Device Via The Configurator
6 dated from June 19, 2018 Preparing of Device via the Configurator Before using Galileosky devices you have to configure them with the help of service software “Configurator” (hereinafter – the Configurator). The order of downloading and installation is the following: Turn on the Windows-based computer and go to the Galileosky web-site using the ... -
Page 9: Monitoring Software Setting
The settings order is the following: Start the monitoring program and go to monitoring object creation section; Specify the name of the object (any), type of the object «GALILEOSKY v 5.0», in unique ID field enter the IMEI of the device;... - Page 10 Switching on Galileosky 5.0, 5.1 Devices for the First Time version 6 dated from June 19, 2018 Pic. 13 Troubleshooting tab The device is ready to operate. RSA “Galileosky”, LLC produces satellite monitoring equipment for GPS and GLONASS real time vehicles monitoring. The tracking devices determine the mobile...
