Stakka Guestbed Frame
Dimensions
Width - 99.5cm
Depth - 202.0cm
Height - 45.0cm
– Please read these instructions fully before starting assembly
Important
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400 800
- Please keep for future reference
632/0973
632/0966
Issue 1 - 29/03/11
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Argos Stakka 632/0973
Summary of Contents for Argos Stakka 632/0973
- Page 1 Stakka Guestbed Frame 632/0973 - Please keep for future reference Assembly Instructions 632/0966 Dimensions Width - 99.5cm Depth - 202.0cm Height - 45.0cm – Please read these instructions fully before starting assembly Important If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400 800 Issue 1 - 29/03/11...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly . Check you have all the Assemble on a soft level We do not surface to avoid damaging the recommend the components and tools listed on pages 2 and 3.
- Page 3 Components - Panels Please check you have all the panels listed below 01 Feet x 2 02 Feet x 2 (22.5 x 6cm) (22.5 x 6cm) 03 Feet x 2 04 Feet x 2 (22.5 x 6cm) (22.5 x 6cm) 05 Headboard / Footboard rail x 8 06 Side rails x 4 (87.5 x 9cm)
- Page 4 If you have damaged or missing components, Components - Fittings call the Customer Helpline: 08456 400 800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 Assembly Instructions Step 1 Fitting dowels Insert dowels into the indicated parts. Step 2 Assembling headboard and footboard: Fix the Feet to the Headboard / Footboard Rails shown using long screw and allen key Caution: Make sure to fix the correct feet and in the correct position as shown in the pictures.
- Page 6 Assembly Instructions Step 3 Assembling bottom bed: Insert half moon nut into side rails as shown. Then fix them to using bolts and allen key Caution: Assembling of Step 3 and Step 4 will be easier with 2 people. It can also avoid damages or brakes of any part or component.
- Page 7 Assembly Instructions Step 5 Assembling top bed: Insert half moon nut into side rails as shown. Then fix them to using bolts and allen key Caution: Assembling of Step 5 and Step 6 will be easier with 2 people. It can also avoid damages or brakes of any part or component.
- Page 8 Assembly Instructions Step 7 Fixing slats: Fix the slats adjacent to the headboard working towards the middle of the bed using the spacer as shown to ensure correct spacing. Fix using screws .Periodically check that all screws are tight. Step 8 Two people will be needed for this step.
