Alex Headboard
Step 7
Assembly Instructions
Dimensions
Width x Depth x Height
92cm x 5cm x 53.5/105cm (Single)
136cm x 5cm x 53.5/105cm (Double)
Important
- Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the
- Please keep for future reference
Customer Helpline:0345 6400800
634/1880
634/1897
634/3541
634/3558
Issue 2 - 25/10/14
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Alex Headboard 634/1880
Summary of Contents for Argos Alex Headboard 634/1880
- Page 1 Alex Headboard Step 7 Assembly Instructions 634/1880 - Please keep for future reference 634/1897 634/3541 634/3558 Dimensions Width x Depth x Height 92cm x 5cm x 53.5/105cm (Single) 136cm x 5cm x 53.5/105cm (Double) Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline:0345 6400800 Issue 2 - 25/10/14...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Assemble the item as close • To reduce components and tools listed on to its fi nal position (in the same the lik elihood of room) as possible.
- Page 3 Components If you have damaged or missing components, call the Customer Helpline:0345 6400800 Please check you have all the parts listed below (Single) (Double) 1 Headboard 2 Support arms x 2...
- Page 4 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. M8 Bolt x 4 M8 Flat washer x 4 Tools required Phillips screwdriver Ruler - Use this ruler to help correctly identify the screws...
- Page 5 Assembly Instructions Attaching support arms Attach the two support arms to the rear of the headboard using bolts and washers shown. Assembly is complete.
