Misaki - Double Bed

Assembly Instructions -

Dimensions

Width - 141cm

Length - 199cm

Height - 75.5cm

Important -

Please read these instructions fully before starting assembly

If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800

Please keep for future reference

632/4546

632/4553

MADE IN

BRITAIN

Issue 1 - 09/12/10

Need help?

Do you have a question about the Misaki 632/4546 and is the answer not in the manual?

Questions and answers

Summary of Contents for Argos Misaki 632/4546

Page 1 Misaki - Double Bed Assembly Instructions - 632/4546 Please keep for future reference 632/4553 Dimensions Width - 141cm Length - 199cm MADE IN Height - 75.5cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 1 - 09/12/10...
Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 63kgs. space to layout the parts before recommend the Please lift with care. starting.
Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below End Panel 2 Side Rail (D0690A) (D0691A) (1403 x 312mm) (1904 x 133mm) Mid Rail Footboard...
Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Prepare the mid rail Push 2 barrel nuts into the mid rail 10mm Screw a metal dowel into the mid rail Note: Tighten metal dowels up fully against the panels.
Page 6 Assembly Instructions Step 3 This upper hole is not used Join the mid rail and blanking returns Push the 2 blanking returns onto the mid rail Use a screwdriver to This lower hole tighten the large locking is not used fitted to each of the blanking returns as shown.
Page 7 Assembly Instructions Step 6 Prepare 1 of the end panels Screw 4 metal dowels into only 1 of the end panels Step 7 Fit an end panel Push the end panel onto the assembly. Note: Make sure that the slot in the barrel nut is horizontal in the mid rail Use a screwdriver to...
Page 8 Assembly Instructions Step 8 Prepare the 2 side rails Push 2 barrel nuts into each side rail Tap 4 wooden dowels into each side rail Step 9 Fit the side rails Push the side rails onto the end panel Screw through the end panel using bolts and allen key...
Page 9 Assembly Instructions Step 10 Fit the other end panel Push the other end panel onto the assembly. Screw through the end panel using bolts and allen key and on into the barrel nuts fitted in the mid rail and side rails Step 11 Fit the footboard Fit the footboard...
Page 10 Assembly Instructions Step 12 Fit the headboard struts Fit the middle headboard strut using 2 screws To fit the other 2 headboard struts push the connecting sleeves into the holes and then screw the screws in from the other side. Step 13 Fit the headboard Fix the headboard...
Page 11 Assembly Instructions Step 14 Prepare the 2 drawer fronts Screw 8 metal dowels into the drawer front Step 15 Prepare the left and right drawer end Insert 2 large locking nuts into the left drawer end and right drawer end Tap a wooden dowel into the left drawer end and right drawer end...
Page 12 Assembly Instructions Step 18 Join the drawer ends to the drawer front Push the left drawer end and right drawer end onto the drawer front Use a screwdriver to tighten the large locking fitted to the left drawer end and right drawer end Step 19 Fit the drawer bottom...
Page 13 Assembly Instructions Step 21 Fit the drawer back Push the drawer back down between the left drawer end and right drawer end and onto the drawer base Make sure that the drawer base goes up into the groove of the drawer back Fix the drawer back to the drawer ends...
Page 14 Assembly Instructions Step 24 Insert the drawers...
Page 15 Lift with care. If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW...
Page 16 ALR2560...

This manual is also suitable for:

Misaki 632/4553
