Quick Guide for the V-Tap VoIP 1 & 2
Windows Vista/7/8/10 , Intel Pentium >2GHz , 4GByte RAM , >100 MB free disk space.
1. Connect the V-Tap VoIP to a free USB port on your PC.
NOTE: The V-Tap VoIP must be connected to the same PC, otherwise the installer will not continue.

2. V-Archive software installation

•
Place the CD-ROM in your computer and the software installation starts automatically. In case the
installation does not start, locate the file 'VArchiveInstall.exe' (former 'CRVoIPInstall.exe') on the
CD and start it manually. The following window appears:
•
Select your preferred language for the installation and press OK.
•
The menu will ask for an installation key, please enter:
•
Now you can proceed with the next steps of the installation and you will be asked to confirm the
locations on your hard drive where to store the software and the data files.
NOTE: A separate installation of the WinPcap driver may be needed and is started automatically,
depending on the absence of this low-level network interface driver.
To setup V-Archive to receive data from the V-Tap, go to Options, Setup, Recording tab:
•
NOTE1: The PC's IP address must be entered as the "Tunnel Server Address" in the V-Tap unit.
NOTE2: The PC's firewall must be open for TCP port 2016, the "Tunnel Destination Port" in the V-Tap unit.
NOTE3: The Encryption password must be the same as the "Tunnel Encryption Password" in the V-Tap unit.
NOTE4: The V-Archive software itself does not need channel licenses to receive from the V-Tap unit.
v1.12
